MAX17332X22 Integrated Circuit Chip with AccuCharge Technology and ModelGauge m5 EZ Algorithm for 1-Cell Lithium-Ion/Polymer Batteries

MAX17332X22 Integrated Circuit Chip with AccuCharge Technology and ModelGauge m5 EZ Algorithm for 1-Cell Lithium-Ion/Polymer Batteries
MAX17332X22 Integrated Circuit Chip with AccuCharge Technology and ModelGauge m5 EZ Algorithm for 1-Cell Lithium-Ion/Polymer Batteries

Large Image :  MAX17332X22 Integrated Circuit Chip with AccuCharge Technology and ModelGauge m5 EZ Algorithm for 1-Cell Lithium-Ion/Polymer Batteries

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MAX17332X22
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: WLP-15
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

MAX17332X22 Integrated Circuit Chip with AccuCharge Technology and ModelGauge m5 EZ Algorithm for 1-Cell Lithium-Ion/Polymer Batteries

Description
Part Number: MAX17332X22 Battery Chemistry: Lithium Ion/Polymer
Battery Pack Voltage: 4.8V (Max) Number Of Cells: 1
Voltage - Supply (Max): 4.9V Operating Temperature: -40°C ~ 85°C (TA)
Highlight:

1-Cell Lithium-Ion/Polymer Integrated Circuit Chip

,

AccuCharge Technology IC Chip

,

ModelGauge m5 EZ Algorithm Battery Management IC

MAX17332 Integrated Circuit Chip AccuCharge + ModelGauge m5 EZ 1-Cell Charger Fuel Gauge And Protector
Product Overview Of  MAX17332

MAX17332 is a 35μA IQ stand-alone charger, fuel gauge, protector, and battery internal self-discharge detection IC for 1-cell lithium-ion/polymer batteries. When a voltage source is present, the IC regulates charging by modulating the charge N-FET, using AccuCharge™ charger technology. The IC regulates charge voltage, current, and FET temperature. Stand-alone charging is supported by flexible configuration in nonvolatile memory.

Specifications Of MAX17332
Product Category Battery Management
Product Charge Management
Battery Type Lithium-ion
Operating Supply Voltage 2.16 V to 4.9 V
Package / Case WLP-15
Mounting Style SMD/SMT
Maximum Operating Temperature +85℃
Minimum Operating Temperature -40℃
Operating Supply Current 35 uA
Key Features Of MAX17332
Charging Capabilities
  • Non-Volatile Programmable Stand-Alone Charger
  • 1% Charge Current, 256 Current Settings
  • 0.25% Charge Voltage, 2.42V to 4.8V, Configurable
  • Optional Manual Charge Control
  • FET Temperature Limit and Heat Regulation
  • Prequal, SmartFull, and Step-Charging Options
  • JEITA--9 Temperature Regions
Battery Protection & Safety
  • Battery Health + Programmable Safety/Protection
  • Overvoltage/Overcharge Current
  • Temperature Region Dependent
  • Overcharge/Discharge/Short-Circuit Current
  • Over/Under Temperature
  • Zero-Volt or >1.8V Charging Option
  • Undervoltage + SmartEmpty
Advanced Monitoring
  • ModelGauge m5 EZ Algorithm
  • Percent, Capacity, Time-to-Empty/Full, Age
  • Cycle+™ Age Forecast + Age-Scheduled Charging
  • Dynamic Power--Estimates Power Capability
  • SHA-256 Authentication to Prevent Cloning
  • Precision Measurement Without Calibration
  • Current, Voltage, Power, Time, Cycles
Power Management
  • Die Temperature and two Thermistors
  • History Logging, User Data
  • Low Quiescent Current
  • FETs Enabled: 35μA Active, 21μA Hibernate
  • FETs Disabled: 8μA Ship, 0.5μA Shutdown
  • 2-Wire (I2C) and 1-Wire®
  • 1.9 mm x 2.5 mm 15-Bump 0.5mm Pitch Wafer-Level Package (WLP)
Applications Of MAX17332
USB PPS and Direct ChargingSmart Batteries and Hybrid Supercap BatteriesDual Screen Smartphones, TabletsHearables, Wearables, SmartwatchesMedical Devices, Health, Fitness MonitorsHandheld Radios, Computers, AccessoriesHome/Building Automation, Sensors, CamerasParallel Battery AR/VR Systems
