LT3062 Integrated Circuit Chip Micropower Low Dropout Linear Regulator 200mA LDO Regulator
LT3062 Integrated Circuit Chip Micropower Low Dropout Linear Regulator 200mA LDO Regulator
Product Description Of LT3062
LT3062 is a micropower, low dropout (LDO) linear regulator that operates over a 1.6V to 45V supply range and is available in a series of fixed output and adjustable versions. The device supplies 200mA of output current with a typical dropout voltage of 300mV. A single external capacitor provides programmable low noise reference performance and output soft-start functionality. The LT3062's quiescent current is merely 45μA and provides fast transient response with a minimum 3.3μF output capacitor. In shutdown, quiescent current is less than 1μA and the reference soft start capacitor is reset.
Specification Of LT3062
| Product Category: |
LDO Voltage Regulators |
| Mounting Style: |
SMD/SMT |
| Package / Case: |
MSOP-E-8 |
| Output Voltage: |
5 V |
| Output Current: |
200 mA |
| Number of Outputs: |
1 Output |
| Polarity: |
Positive |
| Quiescent Current: |
300 nA |
| PSRR / Ripple Rejection - Typ: |
70 dB |
| Output Type: |
Fixed |
| Minimum Operating Temperature: |
-40 ℃ |
| Maximum Operating Temperature: |
+125 ℃ |
| Dropout Voltage: |
300 mV |
| Dropout Voltage - Max: |
530 mV |
| Line Regulation: |
3.1 mV |
| Load Regulation: |
7.6 mV |
Features Of LT3062
- Input Voltage Range: 1.6V to 45V
- Output Current: 200mA
- Quiescent Current: 45μA
- Dropout Voltage: 300mV
- Low Noise: 30μVRMS (10Hz to 100kHz)
- Adjustable Output (VREF = 600mV)
- Fixed Output Voltages: 3.3V, 5V
- Output Tolerance: ±2% Over Load, Line, and Temperature
- Single Capacitor Soft-Starts Reference and Lowers Output Noise
- Shutdown Current: < 1μA
- Reverse Battery Protection
- Current Limit Foldback and Thermal Limit Protection
Applications Of LT3062
- Battery Powered Systems
- Automotive Power Supplies
- Industrial Power Supplies
- Avionic Power Supplies
- Portable Instruments
