TLE5014S16 GMR Principle Magnetic Angle Sensor IC with 360° Measurement and ISO 26262 ASIL C/D Compliance

TLE5014S16 GMR Principle Magnetic Angle Sensor IC with 360° Measurement and ISO 26262 ASIL C/D Compliance
TLE5014S16 GMR Principle Magnetic Angle Sensor IC with 360° Measurement and ISO 26262 ASIL C/D Compliance

Large Image :  TLE5014S16 GMR Principle Magnetic Angle Sensor IC with 360° Measurement and ISO 26262 ASIL C/D Compliance

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TLE5014S16
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TDSO-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

TLE5014S16 GMR Principle Magnetic Angle Sensor IC with 360° Measurement and ISO 26262 ASIL C/D Compliance

Description
Part Number: TLE5014S16 Rotation Angle - Electrical, Mechanical: 0° ~ 360°
Voltage - Supply: 4.2V ~ 5.5V Operating Temperature: -40°C ~ 125°C
Package: PG-TDSO-16 Output Signal: Cosine, Sine
Highlight:

GMR Principle Magnetic Angle Sensor

,

360° Measurement Sensor IC

,

ISO 26262 ASIL C/D GMR Angle Sensor

TLE5014S16 Sensor IC Magnetic Angle Sensor Based On GMR Principle PG-TDSO-16
Product Overview Of TLE5014
TLE5014 magnetic angle sensors are available as single and dual die products, pre-configured and pre-calibrated for easy use. Interface options include SENT/PWM/SPC (preconfigured) and SPI. The sensor configuration is adaptable using a programmable E²PROM. TLE5014 sensors meet ISO 26262 ASIL C (single chip) and ASIL D (dual chip) standards for high functional safety applications.
Specifications Of TLE5014
Parameter Value
Operating Supply Current 12 mA
Operating Supply Voltage 4.2 V to 5.5 V
Minimum Operating Temperature -40°C
Maximum Operating Temperature +125°C
Supply Voltage - Max 5.5 V
Supply Voltage - Min 4.2 V
Resolution 12 bit
Sensitivity 12 bit
Key Features Of TLE5014
  • GMR principle
  • Less than 1° angle error over lifetime
  • 360° measurement revolution counter
  • Interfaces: PWM, SPC, SENT
  • High V & reverse polarity robustness
  • On-device linear angle compensation
  • ISO 26262 Safety Element out of Context
Applications Of TLE5014
  • Active suspension control
  • Electric power steering (EPS)
  • Automotive electric pumps & fans 12 V
  • Drones
Product Tags
TLE5014S16 TLE5014S1 TLE5014S TLE5014
Frequently Asked Questions
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample? Is the sample free?
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
