TPS22965NTDSGRQ1 Integrated Circuit Chip 5.5V 4A 16mΩ On-Resistance Automotive Load Switch

Description
Part Number: TPS22965NTDSGRQ1 Number Of Outputs: 1
Ratio - Input:Output: 1:1 Voltage - Load: 2.5V ~ 5.5V
Voltage - Supply (Vcc/Vdd): 0.8V ~ 5.5V Current - Output (Max): 4A
Highlight:

5.5V Integrated Circuit Chip

,

4A Load Switch

,

16mΩ On-Resistance Automotive IC

TPS22965NTDSGRQ1 Integrated Circuit Chip 5.5V 4A 16mΩ On-Resistance Automotive Load Switch
Product Overview Of TPS22965

The TPS22965 is a compact, ultra-low RON single-channel load switch with controlled turn-on. This device features an N-channel MOSFET operating within an input voltage range of 0.8V to 5.5V, supporting maximum continuous current of 4A. The configurable VOUT rise time helps reduce inrush current, and includes a 225-Ω on-chip load resistor for quick output discharge when the switch is turned off.

Technical Specifications Of TPS22965
Type Load Switch
Number of Outputs 1 Output
Output Current 6 A
On Resistance - Max 21 mOhms
On Time - Max 1.6 ms
Off Time - Max 9 us
Operating Supply Voltage 800 mV to 5.7 V
Minimum Operating Temperature -40°C
Maximum Operating Temperature +105°C
Supply Voltage - Max 5.5 V
Supply Voltage - Min 800 mV
Unit Weight 76 mg
Key Features Of TPS22965
  • Qualified for automotive applications
  • AEC-Q100 qualified
  • Device temperature grade 2: -40°C to +105°C (TPS22965-Q1, TPS22965N-Q1)
  • Device temperature grade 1: -40°C to +125°C (TPS22965W-Q1, TPS22965NW-Q1)
  • Device HBM ESD classification level 3A
  • Device CDM ESD classification level C6
  • Functional Safety-Capable
  • Documentation available to aid functional safety system design
  • Integrated single channel load switch
  • Input voltage range: 0.8V to 5.5V
  • Ultra-low on resistance (RON): 16mΩ at various voltage configurations
  • 4-A maximum continuous switch current
  • Low quiescent current (50µA)
  • Low control input threshold enables use of 1.2V, 1.8V, 2.5V and 3.3V logic
  • Configurable rise time
  • Quick Output Discharge (QOD) (TPS22965-Q1 and TPS22965W-Q1 only)
  • WSON 8-pin package with thermal pad
Applications Of TPS22965
  • Automotive electronics
  • Infotainment systems
  • ADAS (Advanced Driver Assistance Systems)
Product Identification
TPS22965NTDSGRQ1, TPS22965NTDSGRQ, TPS22965NTDSGR, TPS22965NTDSG, TPS22965NTDS, TPS22965NTD, TPS22965NT, TPS22965N, TPS22965
