AD8138ARMZ Integrated Circuit Chip ADC Driver with 320 MHz Gain Bandwidth 1150 V/us Slew Rate and Low Distortion

AD8138ARMZ Integrated Circuit Chip ADC Driver with 320 MHz Gain Bandwidth 1150 V/us Slew Rate and Low Distortion
AD8138ARMZ Integrated Circuit Chip ADC Driver with 320 MHz Gain Bandwidth 1150 V/us Slew Rate and Low Distortion

Large Image :  AD8138ARMZ Integrated Circuit Chip ADC Driver with 320 MHz Gain Bandwidth 1150 V/us Slew Rate and Low Distortion

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: AD8138ARMZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: MSOP-8​
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

AD8138ARMZ Integrated Circuit Chip ADC Driver with 320 MHz Gain Bandwidth 1150 V/us Slew Rate and Low Distortion

Description
Part Number: AD8138ARMZ Type: ADC Driver
GBP - Gain Bandwidth Product: 320 MHz SR - Slew Rate: 1150 V/us
CMRR - Common Mode Rejection Ratio: - 77 DB Pd - Power Dissipation: 550 MW
Highlight:

320 MHz Gain Bandwidth Integrated Circuit Chip

,

1150 V/us Slew Rate ADC Driver

,

Low Distortion Differential Amplifier

AD8138 Integrated Circuit Chip Low Distortion Differential ADC Driver MSOP-8
Product Overview Of AD8138

The AD8138 represents a significant advancement over traditional op amps for differential signal processing. This integrated circuit can function as either a single-ended-to-differential amplifier or a differential-to-differential amplifier, offering exceptional ease of use while simplifying differential signal amplification and driving applications.

Manufactured using ADI's proprietary XFCB bipolar process, the AD8138 delivers a -3 dB bandwidth of 320 MHz and produces differential signals with the industry's lowest harmonic distortion available in a differential amplifier.

Specifications Of AD8138
Product Category Differential Amplifiers
Number of Channels 1 Channel
GBP - Gain Bandwidth Product 320 MHz
SR - Slew Rate 1150 V/μs
CMRR - Common Mode Rejection Ratio -77 dB
Output Current per Channel 95 mA
Ib - Input Bias Current 7 μA
Vos - Input Offset Voltage 1 mV
Supply Voltage - Max 11 V
Supply Voltage - Min 3 V
Operating Supply Current 20 mA
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +85 ℃
Mounting Style SMD/SMT
Package / Case MSOP-8
Gain 1 V/V
Maximum Input Resistance 3 MΩ
Pd - Power Dissipation 550 mW
PSRR - Power Supply Rejection Ratio -90 dB
Settling Time 16 ns
Key Features Of AD8138
  • Easy to use, single-ended-to-differential conversion
  • Adjustable output common-mode voltage
  • Externally adjustable gain
  • Low harmonic distortion
  • -94 dBc SFDR at 5 MHz
  • -85 dBc SFDR at 20 MHz
  • -3 dB bandwidth of 320 MHz, G = +1
  • Fast settling to 0.01% of 16 ns
  • Slew rate 1150 V/μs
  • Fast overdrive recovery of 4 ns
  • Low input voltage noise of 5 nV/√Hz
Applications Of AD8138
  • ADC drivers
  • Single-ended-to-differential converters
  • IF and baseband gain blocks
  • Differential buffers
  • Line drivers
