ADG708CRUZ Integrated Circuit Chip CMOS Analog Multiplexer 8:1 Multiplexer with Low Voltage 1.8V to 5.5V and Fast Switching 14ns

ADG708CRUZ Integrated Circuit Chip CMOS Analog Multiplexer 8:1 Multiplexer with Low Voltage 1.8V to 5.5V and Fast Switching 14ns
ADG708CRUZ Integrated Circuit Chip CMOS Analog Multiplexer 8:1 Multiplexer with Low Voltage 1.8V to 5.5V and Fast Switching 14ns

Large Image :  ADG708CRUZ Integrated Circuit Chip CMOS Analog Multiplexer 8:1 Multiplexer with Low Voltage 1.8V to 5.5V and Fast Switching 14ns

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: ADG708CRUZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSSOP-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

ADG708CRUZ Integrated Circuit Chip CMOS Analog Multiplexer 8:1 Multiplexer with Low Voltage 1.8V to 5.5V and Fast Switching 14ns

Description
Part Number: ADG708CRUZ Multiplexer/Demultiplexer Circuit: 8:1
On-State Resistance (Max): 4.5Ohm Switch Time (Ton, Toff) (Max): 14ns, 8ns (Typ)
Channel Capacitance (CS(off), CD(off)): 13pF, 85pF Operating Temperature: -40°C ~ 125°C (TA)
Highlight:

8:1 Multiplexer Integrated Circuit Chip

,

Low Voltage 1.8V to 5.5V CMOS Analog Multiplexer

,

Fast Switching 14ns Multiplexer Switch IC

ADG708CRUZ Integrated Circuit Chip CMOS Analog Multiplexers TSSOP-16 Single 8 To 1 Multiplexer
Product Overview Of ADG708

ADG708 is a low voltage, CMOS analog multiplexer comprising eight single channels. The device switches one of eight inputs (S1-S8) to a common output, D, as determined by the 3-bit binary address lines A0, A1, and A2. An EN input is used to enable or disable the device. When disabled, all channels are switched OFF.

Specifications Of ADG708
Product Category Multiplexer Switch ICs
Product Multiplexers
Mounting Style SMD/SMT
Package / Case TSSOP-16
Number of Channels 8 Channel
Configuration 1 x 8:1
Supply Voltage - Min 1.8 V
Supply Voltage - Max 5.5 V
Minimum Dual Supply Voltage 2.25 V
Maximum Dual Supply Voltage 2.75 V
On Resistance - Max 4.5 Ohms
On Time - Max 14 ns
Off Time - Max 7 ns
Minimum Operating Temperature -40℃
Maximum Operating Temperature +125℃
Operating Supply Voltage 5 V
Bandwidth 55 MHz
Off Isolation - Typ 80 dB
Pd - Power Dissipation 5 uW
Key Features Of ADG708
  • 1.8 V to 5.5 V Single Supply
  • ±2.5 V Dual Supply
  • 3 Ω ON Resistance
  • 0.75 Ω ON Resistance Flatness
  • 100 pA Leakage Currents
  • 14 ns Switching Times
  • Single 8-to-1 Multiplexer ADG708
  • Differential 4-to-1 Multiplexer ADG709
  • 16-Lead TSSOP Package
  • Low Power Consumption
  • TTL-/CMOS-Compatible Inputs
Applications Of ADG708
  • Data acquisition systems
  • Communication systems
  • Relay replacement
  • Audio and video switching
  • Battery-powered systems
