M24256-DRMF3TG 256Kbit Serial I2C Bus EEPROM Memory IC Chip with 1 MHz Clock Frequency

M24256-DRMF3TG 256Kbit Serial I2C Bus EEPROM Memory IC Chip with 1 MHz Clock Frequency
M24256-DRMF3TG 256Kbit Serial I2C Bus EEPROM Memory IC Chip with 1 MHz Clock Frequency

Large Image :  M24256-DRMF3TG 256Kbit Serial I2C Bus EEPROM Memory IC Chip with 1 MHz Clock Frequency

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: M24256-DRMF3TG
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: MLP-8
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

M24256-DRMF3TG 256Kbit Serial I2C Bus EEPROM Memory IC Chip with 1 MHz Clock Frequency

Description
Part Number: M24256-DRMF3TG Memory Size: 256Kbit
Memory Organization: 32K X 8 Memory Interface: I2C
Clock Frequency: 1 MHz Write Cycle Time - Word, Page: 5ms
Highlight:

256Kbit EEPROM Memory

,

I2C Interface Memory IC Chip

,

1 MHz Clock Frequency Serial I2C Bus Memory

M24256-DRMF3TG Memory IC Chip 256Kbit Serial I2C Bus EEPROM Memory MLP-8

M24256 is a 256-Kbit I2C-compatible EEPROM (electrically erasable programmable memory) organized as 32 K × 8 bits.

Specifications Of M24256
Memory Size 256 kbit
Interface Type 2-Wire, I2C
Maximum Clock Frequency 1 MHz
Organisation 32 k x 8
Package/Case MLP-8
Access Time 450 ns
Supply Voltage - Min 1.7 V
Supply Voltage - Max 5.5 V
Data Retention 100 Year
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +125 °C
Active Read Current - Max 2 mA
Operating Supply Current 2 mA
Operating Supply Voltage 1.8 V to 5.5 V
Supply Current - Max 2 mA
Unit Weight 300 mg
Key Features Of M24256
  • Compatible with I2C bus modes: 1 MHz, 400 kHz, 100 kHz
  • 256 Kbit (32 Kbyte) of EEPROM with 64 byte page size
  • Additional write lockable page (M24256-D order codes)
  • Single supply voltage and high speed: 1 MHz clock from 1.7 V to 5.5 V
  • Byte write within 5 ms, Page write within 5 ms
  • Operating temperature range: -40 °C to +85 °C
  • Random and sequential read modes
  • Write protect of the whole memory array
  • Enhanced ESD/latch-Up protection
  • More than 4 million write cycles
  • More than 200-years data retention
  • RoHS-compliant and Halogen-free (ECOPACK2)
  • Available packages: SO8, TSSOP8, UFDFPN8, WLCSP ECOPACK2
  • Unsawn wafer (each die is tested)
