MAX9030AUT Integrated Circuit Chip Low-Cost Ultra-Small Single-Supply Comparator

MAX9030AUT Integrated Circuit Chip Low-Cost Ultra-Small Single-Supply Comparator
MAX9030AUT Integrated Circuit Chip Low-Cost Ultra-Small Single-Supply Comparator

Large Image :  MAX9030AUT Integrated Circuit Chip Low-Cost Ultra-Small Single-Supply Comparator

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MAX9030AUT
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOT-23-6
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

MAX9030AUT Integrated Circuit Chip Low-Cost Ultra-Small Single-Supply Comparator

Description
Part Number: MAX9030AUT Voltage - Supply, Single/Dual: 2.5V ~ 5.5V
Voltage - Input Offset (Max): 1mV @ 5V Current - Input Bias (Max): 0.008µA @ 5V
Current - Quiescent (Max): 55µA Hysteresis: 4mV
Highlight:

Low-Cost Integrated Circuit Chip

,

Ultra-Small Comparator

,

Single-Supply MAX9030AUT

MAX9030AUT Integrated Circuit Chip Low-Cost Ultra-Small 1-Channel Single-Supply Comparators
Product Overview Of MAX9030
The MAX9030 is a 1-channel comparator optimized for single-supply applications from +2.5V to +5.5V, with dual-supply operation capability. Featuring a 188ns propagation delay and consuming only 35µA of supply current per comparator across the -40°C to +125°C operating temperature range, this device combines low-power operation, single-supply capability down to +2.5V, and ultra-small footprint for ideal use in portable applications.
Specifications Of MAX9030
Number of Channels 1 Channel
Output Type Push-Pull
Response Time 188 ns
Comparator Type General Purpose
Supply Voltage - Min 2.5 V
Supply Voltage - Max 5.5 V
Operating Supply Current 55 uA
Vos - Input Offset Voltage 1 mV
Ib - Input Bias Current 8 nA
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +125 °C
Key Features Of MAX9030
  • Low-Cost Solution Available in Space-Saving SC70 Packages
  • +2.5 to +5.5V Single-Supply Voltage Range
  • Comparator Output Swings Rail-to-Rail
  • Internal 4mV Comparator Hysteresis
  • 188ns Propagation Delay
  • Low 35µA Supply Current
  • No Phase Reversal for Overdriven Inputs
Applications Of MAX9030
  • Battery-Powered Portable Systems
  • Digital Line Receivers
  • Keyless Entry Systems
  • Mobile Communications
  • Photodiode Preamps
  • Sensor Signal Detection
  • Threshold Detectors/Discriminators
