ICS-41351 Low Noise Digital Output Multi-Mode MEMS Microphone Integrated Circuit Chip

ICS-41351 Low Noise Digital Output Multi-Mode MEMS Microphone Integrated Circuit Chip
ICS-41351 Low Noise Digital Output Multi-Mode MEMS Microphone Integrated Circuit Chip

Large Image :  ICS-41351 Low Noise Digital Output Multi-Mode MEMS Microphone Integrated Circuit Chip

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: ICS-41351
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LGA-5
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

ICS-41351 Low Noise Digital Output Multi-Mode MEMS Microphone Integrated Circuit Chip

Description
Part Number: ICS-41351 Frequency Range: 50 Hz ~ 20 KHz
Sensitivity: -26dB ±1dB @ 94dB SPL S/N Ratio: 65dB
Voltage - Rated: 1.8 V Current - Supply: 600 µA
Highlight:

Low Noise MEMS Microphone

,

Digital Output Integrated Circuit Chip

,

Multi-Mode Digital Microphone

ICS-41351 Integrated Circuit Chip Low Noise Digital Output Multi-Mode MEMS Microphone
Product Overview Of ICS-41351

The ICS-41351 is a multi-mode, low noise digital MEMS microphone in a compact surface-mount package. This integrated circuit consists of a MEMS microphone element and an impedance converter amplifier followed by a fourth-order Σ-Δ modulator. The digital interface enables pulse density modulated (PDM) output from two microphones to be time multiplexed on a single data line using a single clock.

The ICS-41351 features multiple operational modes including Low Power (AlwaysOn), Standard, and Sleep modes. It delivers high SNR and 120 dB SPL AOP across all operational modes. Available in a standard 3.5 × 2.65 × 0.98 mm surface-mount package, it is reflow solder compatible with no sensitivity degradation.

Specifications Of ICS-41351
Sensitivity -26 dB
SNR - Signal to Noise Ratio 65 dBA
Frequency Range 1 MHz to 2.65 MHz
Operating Supply Current 600 uA
Operating Supply Voltage 1.65 V to 3.63 V
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
Output Type Digital
Port Type Top
Dimensions 3.5 mm × 2.65 mm × 0.98 mm
Sound Pressure Level 160 dB
Supply Voltage - Max 3.63 V
Supply Voltage - Min 1.65 V
Unit Weight 340.595 mg
Key Features Of ICS-41351
  • 3.5 × 2.65 × 0.98 mm surface-mount package
  • Extended frequency response from 50 Hz to >20 kHz
  • Low power: 230 µA in Low-Power Mode
  • Sleep Mode: 12 µA
  • High power supply rejection (PSR): −93 dB FS
  • Fourth-order Σ-Δ modulator
  • Digital pulse density modulation (PDM) output
  • Compatible with Sn/Pb and Pb-free solder processes
  • RoHS/WEEE compliant
Applications Of ICS-41351
  • Smartphones
  • Microphone Arrays
  • Tablets
  • Cameras
  • Bluetooth Headsets
  • Notebook PCs
  • Security and Surveillance
