TPS1HB08BQPWPRQ1 40V Automotive Smart High-Side Switch Integrated Circuit Chip with 70A Output Current in HTSSOP-16 Package

Description
Part Number: TPS1HB08BQPWPRQ1 Output Configuration: High Side
Voltage - Supply (Vcc/Vdd): 3V ~ 28V Current - Output (Max): 70A
Rds On (Typ): 8mOhm Operating Temperature: -40°C ~ 125°C
Highlight:

40V Automotive Integrated Circuit Chip

,

70A Output Current Smart High-Side Switch

,

HTSSOP-16 Package Power Switch IC

TPS1HB08 Integrated Circuit Chip 40V Automotive Smart High-Side Switch HTSSOP-16
Product Overview Of TPS1HB08

TPS1HB08 is a smart high-side switch intended for use in 12V automotive systems. TPS1HB08 integrates robust protection and diagnostic features to establish output port protection even during harmful events like short circuits in automotive systems.

Specifications Of TPS1HB08
Product Category Power Switch ICs - Power Distribution
Type High Side
Number of Outputs 1 Output
Output Current 10 A
Current Limit 6.4 A to 70 A
On Resistance - Max 12 mOhms
On Time - Max 235 us
Off Time - Max 235 us
Operating Supply Voltage 6 V to 18 V
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +125 ℃
Mounting Style SMD/SMT
Package / Case HTSSOP-16
Key Features Of TPS1HB08
  • Single-channel smart high-side switch with 8mΩ RON (TJ = 25°C)
  • Improve system-level reliability through adjustable current limiting
  • Current limit set-point from 6.4A to 70A
  • Version F: 94A fixed ILIM
  • Robust integrated output protection
  • Integrated thermal protection
  • Protection against short to ground and battery
  • Protection against reverse battery events including automatic switch on of FET with reverse voltage
  • Automatic shut off on loss of battery and ground
  • Integrated output clamp to demagnetize inductive loads
  • Configurable fault handling
  • Analog sense output is configurable to accurately measure load current and device temperature
  • Provides fault indication through SNS pin or FLT pin
  • Detection of open load and short-to-battery
Applications Of TPS1HB08
  • Automotive display module
  • 65W Automotive headlight
  • ADAS modules
  • Seat comfort module
  • Transmission control unit
  • HVAC control module
  • Body control modules
  • Incandescent and LED lighting
