88E1512-A0-NNP2C000 Ethernet IC Integrated 10/100/1000Mbps Energy Efficient Ethernet Transceiver QFN-56

The 88E1512 is an integrated 10/100/1000Mbps Energy Efficient Ethernet transceiver. This transceiver implements the Ethernet physical layer portion of the 1000BASE-T, 100BASE-TX, and 10BASE-T standards. Manufactured using standard digital CMOS process, it contains all active circuitry required to transmit and receive data on standard CAT 5 unshielded twisted pair cable.

• 10/100/1000BASE-T IEEE 802.3 compliant
• Multiple Operating Modes: RGMII to Copper, SGMII to Copper, RGMII to Fiber/SGMII, RGMII to Copper/Fiber/SGMII with Auto-Media Detect, Copper to Fiber (1000BASE-X)
• Four RGMII timing modes including integrated delays - eliminates need for adding trace delays on PCB
• Supports 1000BASE-X and 100BASE-FX on Fiber interface along with SGMII
• Supports LVCMOS I/O Standards on the RGMII
• Supports Energy Efficient Ethernet (EEE) - IEEE 802.3az-2010 compliant
• EEE Buffering for seamless support of legacy MACs
• Ultra Low Power consumption
• Integrated MDI termination resistors that eliminate passive components
• Integrated Switching Voltage Regulators
• Supports Green Ethernet with Active Power Save Mode
• Energy Detect and Energy Detect+ low power modes
• IEEE1588 version 2 Time Stamping
• Wake on LAN (WOL) event detection
• Advanced Virtual Cable Tester® (VCT™)
• Auto-Calibration for MAC Interface outputs
• Temperature Sensor
• Supports single 3.3V supply when using internal switching regulator
• I/O pads can be supplied with 1.8V, 2.5V, or 3.3V
