TPS53647RTAR 4-Phase D-CAP+™ Step-Down Buck Controller WQFN-40 Integrated Circuit Chip with 4.5V ~ 17V Input

Description
Part Number: TPS53647RTAR Series: D-CAP+™
Voltage - Input: 4.5V ~ 17V Voltage - Output: 0.25V ~ 1.52V
Operating Supply Current: 8 MA Operating Temperature: -40°C ~ 125°C
Highlight:

4-Phase Step-Down Buck Controller

,

WQFN-40 Integrated Circuit Chip

,

4.5V ~ 17V Input D-CAP+™ Controller

TPS53647 Integrated Circuit Chip 4-Phase D-CAP+™ Step-Down Buck Controller WQFN-40
Product Overview Of TPS53647

TPS53647 is a high-current, multi-phase, step-down controller featuring built-in non-volatile memory (NVM) and PMBus interface. Compatible with NexFET power stages (CSD95372BQ5MC), this device provides 8-bit BOOT voltage selection covering output voltage from 0.5 V to 2.5 V with steps as small as 5 mV, making it ideal for high-current applications requiring accurate output voltage setting. The advanced D-CAP+ architecture with undershoot reduction (USR) and overshoot reduction (OSR) ensures fast transient response, minimal output capacitance, and high efficiency.

Specifications Of TPS53647
Product Category Switching Controllers
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +125 ℃
Mounting Style SMD/SMT
Package / Case WQFN-40
Operating Supply Current 8 mA
Key Features Of TPS53647
  • 8-bit Selectable BOOT Voltage via Pinstrap or NVM: 0.5 V to 2.5 V (down to 5-mV Step)
  • 1-, 2-, 3-, or 4- Phase Operation
  • PMBus System Interface for Telemetry of Voltage, Current, Power, Temperature, and Fault Conditions
  • 1.8-V and 3.3-V PMBus Bias Compatible
  • Fault Reporting: Output Voltage, Output Current, and Temperature
  • Configurable with Non-Volatile Memory (NVM) or Resistor Pinstrap
  • 16 Levels of Programmable OCP with Pinstrap or NVM
  • Fast Transient with DCAP+ Control
  • Optimized Efficiency at Light and Heavy Loads
  • Support Pre-Bias Startup
  • Phase Current Imbalance Detection and Reporting
  • 8 Independent Levels of Overshoot Reduction (OSR) and Undershoot Reduction (USR)
  • Driverless Configuration for Efficient High-Frequency Switching
  • Fully Compatible with CSD95372BQ5MC NexFET Power Stage
  • Accurate, Adjustable Voltage Positioning
  • 300-kHz to 1-MHz Frequency Selections with Closed-loop Frequency Control
  • Patented AutoBalance Phase Balancing
  • Uses TI's Fusion Digital Power Designer GUI
  • Dynamic Phase Shedding with Programmable Current Threshold
  • Conversion Voltage Range: 4.5 V to 17 V
  • Small, 6 mm × 6 mm, 40-Pin, QFN, PowerPAD Package
Applications Of TPS53647
  • Application-Specific Integrated Circuit (ASIC) Power in Communications Equipment
  • High Density Power Solutions
  • Server Power
  • Smart Power Systems
