Description

Part Number:	SGM42500XPS8G	Operating Voltage Range:	7V To 40V
Low On-Resistance:	0.41Ω	Peak Output Current:	3.6A
Interface:	IN1/IN2	Package:	SOIC-8
Highlight:	3.6A Peak Output Current Integrated Circuit Chip , Low On-Resistance 0.41Ω Motor Driver IC , 7V to 40V Operating Voltage H-Bridge Driver

SGM42500XPS8G Integrated Circuit Chip Low Power 3.6A H-Bridge Brushed DC Motor Driver SOIC-8

Product Overview Of SGM42500

The SGM42500 device is a brushed DC motor driver that integrates four N-MOSFETs, capable of supplying up to 3.6A peak current at 40V voltage.

The SGM42500 supports IN1/IN2 PWM interface, allowing PWM signal implementation on the input interface to adjust motor speed. Customers can adjust PWM current limit or torque in real-time via the VREF pin using a controller's DAC output or PWM signal after RC filter.

Key Features Of SGM42500

H-Bridge Motor Driver
Operating Voltage Range: 7V to 40V
Low On-Resistance: 0.41Ω (HS + LS) at +25℃
3.6A Peak Output Current
Interface: IN1/IN2
Adjustable PWM Current Limit in Real-Time
Low Power Standby Mode
Integrated Protection Features:
- Over-Current Protection (OCP)
- Under-Voltage Lockout (UVLO)
- Thermal Shutdown (TSD)
- Auto-Retry
Available in a Green SOIC-8 (Exposed Pad) Package

Applications Of SGM42500

Printers, Vacuum Cleaners Robotics, Industrial Pumps and Valves

Product Tags

SGM42500XPS8G, SGM42500XPS8, SGM42500XPS, SGM42500XP, SGM42500X, SGM42500
