EPM3512AQC208-10N MAX 3000A Series FPGA with 3.3V In-System Programmable and 172 I/O Complex Programmable Logic Device

EPM3512AQC208-10N MAX 3000A Series FPGA with 3.3V In-System Programmable and 172 I/O Complex Programmable Logic Device
EPM3512AQC208-10N MAX 3000A Series FPGA with 3.3V In-System Programmable and 172 I/O Complex Programmable Logic Device

Large Image :  EPM3512AQC208-10N MAX 3000A Series FPGA with 3.3V In-System Programmable and 172 I/O Complex Programmable Logic Device

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: EPM3512AQC208-10N
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PQFP-208
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

EPM3512AQC208-10N MAX 3000A Series FPGA with 3.3V In-System Programmable and 172 I/O Complex Programmable Logic Device

Description
Part Number: EPM3512AQC208-10N Series: MAX® 3000A
Voltage Supply - Internal: 3V ~ 3.6V Number Of Logic Elements/Blocks: 32
Number Of I/O: 172 Operating Temperature: 0°C ~ 70°C (TA)
Highlight:

3.3V In-System Programmable FPGA

,

172 I/O Field Programmable Gate Array

,

MAX 3000A Series Complex Programmable Logic Device

EPM3512AQC208 Field Programmable Gate Array MAX 3000A Complex Programmable Logic Devices
Product Description Of EPM3512AQC208

EPM3512AQC208 is a 3.3V in-system programmable CPLD from the MAX 3000A series. Based on EEPROM technology, it offers features such as non-volatility, plug-and-play operation and in-system programming via JTAG.

Specification Of EPM3512AQC208
Product Category: CPLD - Complex Programmable Logic Devices
Mounting Style: SMD/SMT
Package / Case: PQFP-208
Operating Supply Voltage: 3.3 V
Number of Macrocells: 512 Macrocell
Number of I/Os: 172 I/O
Minimum Operating Temperature: 0 ℃
Maximum Operating Temperature: + 70 ℃
Maximum Operating Frequency: 116.3 MHz
Propagation Delay - Max: 7.5 ns
Memory Type: EEPROM
Number of Gates: 10000
Number of Logic Array Blocks - LABs: 32
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 3 V
Features Of EPM3512AQC208
  • High-performance, low-cost CMOS EEPROM-based programmable logic devices (PLDs) built on a MAX® architecture
  • 3.3-V in-system programmability (ISP) through the built-in IEEE Std. 1149.1 Joint Test Action Group (JTAG) interface with advanced pin-locking capability
  • ISP circuitry compliant with IEEE Std. 1532
  • Built-in boundary-scan test (BST) circuitry compliant with IEEE Std. 1149.1-1990
  • Enhanced ISP features:
    • Enhanced ISP algorithm for faster programming
    • ISP_Done bit to ensure complete programming
    • Pull-up resistor on I/O pins during in-system programming
  • High-density PLDs ranging from 600 to 10,000 usable gates
  • 4.5-ns pin-to-pin logic delays with counter frequencies of up to 227.3 MHz
  • MultiVoltTM I/O interface enabling the device core to run at 3.3 V, while I/O pins are compatible with 5.0-V, 3.3-V, and 2.5-V logic levels
