TPS25970ARPWR Integrated Circuit Chip 7A Electronic Fuse With Accurate Current Monitor and Wide Input Voltage Range

TPS25970ARPWR Integrated Circuit Chip 7A Electronic Fuse With Accurate Current Monitor and Wide Input Voltage Range
TPS25970ARPWR Integrated Circuit Chip 7A Electronic Fuse With Accurate Current Monitor and Wide Input Voltage Range

Large Image :  TPS25970ARPWR Integrated Circuit Chip 7A Electronic Fuse With Accurate Current Monitor and Wide Input Voltage Range

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TPS25970ARPWR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: VQFN-HR-10​
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

TPS25970ARPWR Integrated Circuit Chip 7A Electronic Fuse With Accurate Current Monitor and Wide Input Voltage Range

Description
Part Number: TPS25970ARPWR Function: Electronic Fuse
Accuracy: ±10% Voltage - Input: 2.7V ~ 23V
Current - Output: 7A Operating Temperature: -40°C ~ 125°C (TJ)
Highlight:

7A Current Output Integrated Circuit Chip

,

Accurate Current Monitor Electronic Fuse

,

Wide Input Voltage Range TPS25970ARPWR

TPS25970 Integrated Circuit Chip 7A Electronic Fuse With Accurate Current Monitor VQFN-HR-10
Product Overview Of TPS25970

TPS25970 eFuses is a highly integrated circuit protection and power management solution in a small package. It provides multiple protection modes using very few external components and offers robust defense against overloads, short-circuits, voltage surges, and excessive inrush current.

Specifications Of TPS25970
Product Category Hot Swap Voltage Controllers
Product Controllers & Switches
Current Limit 870 mA to 7.7 A
Supply Voltage - Max 23 V
Supply Voltage - Min 2.7 V
Operating Supply Current 7 A
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +125 ℃
Mounting Style SMD/SMT
Key Features Of TPS25970
  • Wide operating input voltage range: 2.7V to 23V (28V absolute maximum)
  • Integrated FET with low on-resistance: RON = 9.8mΩ (typ.)
  • Fast overvoltage protection with overvoltage clamp (OVC) or adjustable overvoltage lockout (OVLO)
  • Overcurrent protection with load current monitor output (ILM)
  • Active current limit or circuit-breaker options
  • Adjustable threshold (ILIM) 0.87A-7.7A with ±10% accuracy for ILIM > 1.74A
  • Adjustable transient blanking timer (ITIMER) to allow peak currents up to 2 × ILIM
  • Output load current monitor accuracy: ±8% (max)
  • Fast-trip response for short-circuit protection: 550ns (typical) response time
  • Active high enable input with adjustable undervoltage lockout threshold (UVLO)
  • Adjustable output slew rate control (dVdt)
  • Overtemperature protection
  • Small footprint: QFN 2mm × 2mm, 0.45mm pitch
Applications Of TPS25970
  • Server, PC motherboard, and add-in cards
  • Enterprise storage - RAID/HBA/SAN/eSSD
  • Patient monitors
  • Appliances and power tools
  • Retail point-of-sale terminals
  • Smartphones and tablets
