NSM2015-66B5F-DSWR Sensor IC Hall-Effect-Based Current Sensor IC with 66A Current Sensing, Common-Mode Field Rejection, and 320kHz Bandwidth

Description
Part Number: NSM2015-66B5F-DSWR Sensor Type: Hall Effect
Current - Sensing: 66A Sensitivity: 30.3mV/A
Frequency: DC ~ 320kHz Voltage - Supply: 4.5V ~ 5.5V
Highlight:

66A Current Sensing Sensor IC

,

Common-Mode Field Rejection Hall-Effect-Based Current Sensor IC

,

320kHz Bandwidth Integrated Current Sensor

NSM2015 Sensor IC Hall-Effect-Based Current Sensor IC With Common-Mode Field Rejection
Product Overview Of NSM2015

NSM2015 is an integrated path current sensor featuring a very low on-resistance of 0.85mΩ, significantly reducing heat loss on the chip. The sensor detects magnetic fields generated by Busbar current flowing beneath the chip to indirectly measure current. Compared to traditional Shunt+ isolated op-amp current sampling methods, NSM2015 eliminates the need for primary side power supply and offers simplified, convenient layout design.

Specifications Of NSM2015
Parameter Value
For Measuring AC/DC
Sensor Type Hall Effect
Current Sensing 66A
Number of Channels 1
Output Fixed, Voltage
Sensitivity 30.3mV/A
Frequency DC~320kHz
Linearity ±0.2%
Accuracy ±2%
Voltage Supply 4.5V~5.5V
Response Time 1.5µs
Current Supply (Max) 12mA
Operating Temperature -40°C~125°C
Polarization Bidirectional
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Key Features Of NSM2015
  • High bandwidth and fast response time (320kHz bandwidth, 1.5µs response time)
  • High-precision current measurement
  • Differential Hall sets provide immunity to stray fields
  • High isolation level meeting UL standards
  • Working Voltage for Basic Isolation (VWVBI): 1550Vpk / 1097Vrms
  • Withstand isolation voltage (VISO): 5000Vrms
  • Maximum surge isolation withstand voltage (VIOSM): 10kV
  • Maximum surge current (Isurge): 13kA
  • CMTI > 100V/ns
  • CTI(I) compliance
  • Creepage distance/Clearance distance: 8mm
  • Fault Overcurrent Protection
  • NOVOSENSE innovative 'Spin Current' technology for minimal offset temperature drift
  • Fixed output with Vref
  • Operating temperature: -40°C ~ 125°C
  • Primary internal resistance: 0.85mΩ
  • Wide body SOIC16 package
Applications Of NSM2015
  • Solar Systems
  • Industrial Power Supply
  • Motor Control
  • OBC/DCDC/PTC Heater
  • Charging Pile
