NSL21912-Q1HTSXR 12-Channel 20V Automotive Grade 1 LED Driver Integrated Circuit Chip

Description
Part Number: NSL21912-Q1HTSXR Number Of Outputs: 12
Voltage - Output: 20V Current - Output / Channel: 100mA
Dimming: PWM Operating Temperature: -40°C ~ 125°C (TA)
Highlight:

12-Channel LED Driver

,

20V Automotive IC

,

Automotive Grade 1 Integrated Circuit Chip

NSL21912 Integrated Circuit Chip 20V 12-Channel Automotive High-Side Linear LED Driver HTSSOP-24
Product Overview Of NSL21912

The NSL21912 is an automotive high-side LED driver with a supply voltage range of 3.8V to 20V and current output capability of 100mA per channel. The device supports 2-bit global and 6-bit individual current settings, along with flexible 12-bit PWM dimming.

Featuring a low dropout voltage requirement (700mV Max.@50mA) and supporting automatic thermal sharing via VS shunt resistors, the NSL21912 delivers excellent thermal performance.

The device supports multiple regulations with LED open-circuit, short-to-ground, and single LED short-circuit diagnostics. It integrates a configurable watchdog and programmable EEPROM, allowing flexible fail-safe mode configuration for different applications when MCU connection is lost.

Specifications Of NSL21912
  • Type: Linear
  • Number of Outputs: 12
  • Voltage - Supply (Min): 3V
  • Internal Switch(s): Yes
  • Voltage - Supply (Max): 20V
  • Voltage - Output: 20V
  • Current - Output / Channel: 100mA
  • Dimming: PWM
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 24-HTSSOP
Key Features Of NSL21912
  • Qualified for Automotive Grade 1: Tj from -40°C to 150°C
  • 3.8V~20V supply voltage range
  • 12-channel high side current sources
  • 100mA output current capacity per channel
  • 12-bit independent PWM dimming
  • Low dropout voltage 700mV max. at 50mA
  • Automatic thermal sharing via VS shunt resistor
  • UART-based communication interface (up to 2Mbps)
  • Configurable LED open and LED short detect threshold
  • Full protections and diagnostics
Applications Of NSL21912
  • Automotive rear lighting
  • Automotive exterior lighting
  • General automotive body lighting applications
