TLV2548IPWR 12-Bit 200kSPS Analog to Digital Converter with SPI Interface TSSOP-20

TLV2548IPWR 12-Bit 200kSPS Analog to Digital Converter with SPI Interface TSSOP-20
TLV2548IPWR 12-Bit 200kSPS Analog to Digital Converter with SPI Interface TSSOP-20

Large Image :  TLV2548IPWR 12-Bit 200kSPS Analog to Digital Converter with SPI Interface TSSOP-20

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TLV2548IPWR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSSOP-20
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

TLV2548IPWR 12-Bit 200kSPS Analog to Digital Converter with SPI Interface TSSOP-20

Description
Part Number: TLV2548IPWR Number Of Bits: 12
Sampling Rate (Per Second): 200k Data Interface: SPI, DSP
Voltage - Supply, Analog: 2.7V ~ 5.5V Operating Temperature: -40°C ~ 85°C
Highlight:

12-Bit Analog to Digital Converter

,

200kSPS ADC

,

SPI Interface Integrated Circuit Chip

TLV2548 Integrated Circuit Chip 200kSPS 12-Bit Analog To Digital Converter TSSOP-20

TLV2548 Integrated Circuit Chip 200kSPS 12-Bit Analog To Digital Converter TSSOP-20

TLV2548 is a high-performance, 12-bit low power, 3.86 µs, CMOS analog-to-digital converter (ADC) which operates from a single 2.7-V to 5.5-V power supply. It features three digital inputs and a 3-state output [chip select (CS), serial input-output clock (SCLK), serial data input (SDI), and serial data output (SDO)] that provide a direct 4-wire interface to the serial port of most popular host microprocessors (SPI interface).

Specifications Of TLV2548
Product Category: Analog to Digital Converters - ADC
Mounting Style: SMD/SMT
Package / Case: TSSOP-20
Resolution: 12 bit
Number of Channels: 8 Channel
Interface Type: SPI
Sampling Rate: 200 kS/s
Input Type: Single-Ended
Architecture: SAR
Analog Supply Voltage: 2.7 V to 5.5 V
Digital Supply Voltage: 2.7 V to 5.5 V
Minimum Operating Temperature: -40℃
Maximum Operating Temperature: +85℃
DNL - Differential Nonlinearity: ±1 LSB
Features: Oscillator
INL - Integral Nonlinearity: ±1 LSB
Number of Converters: 1 Converter
Pd - Power Dissipation: 977 mW
Power Consumption: 3.3 mW
Reference Type: External, Internal
SINAD - Signal to Noise and Distortion Ratio: 70 dB
Key Features Of TLV2548
  • Maximum Throughput 200-KSPS
  • Built-In Reference, Conversion Clock and 8× FIFO
  • Differential/Integral Nonlinearity Error: ±1 LSB
  • Signal-to-Noise and Distortion Ratio: 70 dB, fi = 12-kHz
  • Spurious Free Dynamic Range: 75 dB, fi = 12-kHz
  • SPI (CPOL = 0, CPHA = 0)/DSP-Compatible Serial Interfaces With SCLK up to 20-MHz
  • Single Wide Range Supply 2.7 Vdc to 5.5 Vdc
  • Analog Input Range 0-V to Supply Voltage With 500 kHz BW
  • Hardware Controlled and Programmable Sampling Period
  • Low Operating Current (1.0-mA at 3.3-V, 1.1-mA at 5.5-V With External Ref)
  • Power Down: Software/Hardware Power-Down Mode (1 µA Max, Ext Ref), Autopower-Down Mode (1 µA, Ext Ref)
  • Programmable Auto-Channel Sweep
