TC78B002FNG 18V 1.5A Single Phase Full-Wave Driver IC Chip for Fan Motor

Large Image : TC78B002FNG 18V 1.5A Single Phase Full-Wave Driver IC Chip for Fan Motor

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	TC78B002FNG

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	SSOP-16
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10000 Pieces per Day

Contact Now

TC78B002FNG 18V 1.5A Single Phase Full-Wave Driver IC Chip for Fan Motor

Description

Part Number:	TC78B002FNG	Current - Output:	1.5A
Voltage - Supply:	3.5V ~ 16V	Voltage - Load:	3.5V ~ 16V
Operating Temperature:	-40°C ~ 105°C (TA)	Pd - Power Dissipation:	960 MW
Highlight:	18V Integrated Circuit Chip , 1.5A IC Chip , Single Phase Full-Wave Driver IC

TC78B002FNG Integrated Circuit Chip 18V 1.5A Single Phase Full-Wave Driver For Fan Motor

Product Overview Of TC78B002

TC78B002 is a single phase full-wave driver for fan motor. It features a DMOS device in an output transistor, enabling highly effective drive through low ON resistance and PWM drive system.

Specifications Of TC78B002

Product Type	Fan / Motor Controllers / Drivers
Type	Single Phase
Output Current	1.5 A
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+105°C
Supply Voltage - Max	16 V
Supply Voltage - Min	5.5 V
Number of Outputs	2 Output
Operating Frequency	10 MHz
Output Voltage	18 V

Key Features Of TC78B002

Single-phase full-wave drive
Motor power supply voltage: VM = 16V (maximum operating range)
Output current: Iout = 1.5A (max.)
PWM control
Built-in oscillation circuit (External resistor)
Soft switching drive
Lock protection with automatic recovery
Quick start capability
Built-in hall bias
Rotation Speed Detection (FG) and Lock Detection (RDO) Output
Current limit function
Built-in over current protection
Built-in thermal shut down circuit

Applications Of TC78B002

Fan Motor Driver

Product Identification

Product Tags: TC78B002FNG, TC78B002FN, TC78B002F, TC78B002
