S29GL064S70TFI060 64Mbit GL-S Series NOR Flash Memory IC Chip TSOP-48 2.7V ~ 3.6V

S29GL064 is a 64 Mbit MIRRORBIT™ parallel NOR Flash memory device from the GL-S series, commonly used for embedded code storage, FPGA configuration, BIOS and firmware, amongst other applications.

• Distinctive characteristics - CMOS 3.0 V core with versatile I/O
• Architectural advantages - Single power supply operation, manufactured on 65-nm MIRRORBIT™ process technology, secure silicon region
• 128-word/256-byte sector for permanent, secure identification through an 8-word / 16-byte random electronic serial number, accessible through a command sequence
• Programmed and locked at the factory or by the customer
• Flexible sector architecture - 64 Mb (uniform sector models): One hundred twenty-eight 32-Kword (64-KB) sectors; 64 Mb (boot sector models): One hundred twenty-seven 32-Kword (64-KB) sectors + eight-4 Kword (8-KB) boot sectors
• Automatic error checking and correction (ECC) - internal hardware ECC with single bit error correction
• Performance characteristics - High performance: 70 ns access time, 8-word / 16-byte page read buffer, 15 ns page read time, 128-word / 256-byte write buffer which reduces overall programming time for multiple word updates
• Low-power consumption - 25 mA typical initial read current at 5 MHz, 7.5 mA typical page read current at 33 MHz, 50 mA typical erase / program current, 40 µA typical standby mode current
