IS42S32800J-7TLI 256Mbit 143 MHz SDRAM Memory IC Chip TSOP-II-86 Dynamic Random-Access Memory

IS42S32800 is a 256Mbit, high speed CMOS, dynamic random-access memory designed to operate in 3.3V Vdd and 3.3V Vddq memory systems containing 268,435,456 bits. Internally configured as a quad-bank DRAM with a synchronous interface. Each 67,108,864-bit bank is organized as 4,096 rows by 512 columns by 32 bits.

• Clock frequency: 166, 143, 133 MHz
• Fully synchronous; all signals referenced to a positive clock edge
• Internal bank for hiding row access/precharge
• Single Power supply: 3.3V + 0.3V
• LVTTL interface
• Programmable burst length (1, 2, 4, 8, full page)
• Programmable burst sequence: Sequential/Interleave
• Auto Refresh (CBR)
• Self Refresh
• 4096 refresh cycles every 16ms (A2 grade) or 64 ms (Commercial, Industrial, A1 grade)
• Random column address every clock cycle
• Programmable CAS latency (2, 3 clocks)
• Burst read/write and burst read/single write operations capability
• Burst termination by burst stop and precharge command
