LM35DZ Sensor IC Precision Temperature Sensor with 10mV/°C Output 4V to 30V Supply and 0°C to 100°C Range

The LM35DZ is a precision integrated-circuit temperature sensor with an output voltage linearly proportional to Centigrade temperature. Unlike Kelvin-calibrated sensors, the LM35 eliminates the need to subtract a large constant voltage from the output, providing convenient Centigrade scaling directly. The device requires no external calibration or trimming and delivers typical accuracies of ±¼°C at room temperature and ±¾°C across the full −55°C to 150°C temperature range.

• Calibrated Directly in Celsius (Centigrade)
• Linear +10-mV/°C Scale Factor
• 0.5°C Ensured Accuracy (at 25°C)
• Rated for Full −55°C to 150°C Range
• Suitable for Remote Applications
• Low-Cost Due to Wafer-Level Trimming
• Operates From 4 V to 30 V
• Less Than 60-µA Current Drain
• Low Self-Heating, 0.08°C in Still Air
• Non-Linearity Only ±¼°C Typical
• Low-Impedance Output, 0.1 Ω for 1-mA Load

• Power Supplies
• Battery Management
• HVAC
• Appliances
