ASM1083 Integrated Circuit Chip PCIe To PCI Bridge Controller In LQFP-128 Package

ASM1083 Integrated Circuit Chip PCIe To PCI Bridge Controller In LQFP-128 Package

Product Description
The ASM1083, x1 PCI Express to 32-bit PCI Bridge, enables users to connect legacy parallel bus devices to the advanced serial PCI Express interface. The ASM1083 is a PCI Express-to-PCI forward bridge, fully compliant with PCI-SIG PCI Express-to-PCI Bridge Specification1.0.

Features
General Feature
I2C Serial EEPROM support
Extensive PME support
3.3/1.2V power supply
Legacy mode support
Industry Specifications Compliance:
→ PCI Express Base Specification Rev. 1.0a/ 1.1
→ PCI Bus Power Management Interface Rev.2.0
→ PCI Express Card Electromechanical Rev.2.0
→ PCI Specification Rev.3.0
→ PCIE to PCI/PCIX Bridge Specification Rev.1.0
14mmx14mm 128-pin LQFP package
Green package with RoHs compliance

PCI Express Features
x1 PCI Express lane, at 2.5GHz signaling
Single virtual channel
SSC support
ECRC and Advanced Error Reporting capability
100-MHz differential PCI Express reference clock in
Maximum Payload Size up to 128 bytes
No PCIe ASPM support

PCI Features
Support PCI bus 33 MHz
Support 3 PCI masters
CLKRUN support
PME support
5V tolerance

Other Electronic Components In Stock

FAQ
Q: Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample?Is the sample free?
A: Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
