LTM4630AIY Integrated Circuit Chip DC/DC μModule Regulator with 36A Output 4.5V to 18V Input and 0.6V to 8V Output

LTM4630AIY Integrated Circuit Chip DC/DC μModule Regulator with 36A Output 4.5V to 18V Input and 0.6V to 8V Output
LTM4630AIY Integrated Circuit Chip DC/DC μModule Regulator with 36A Output 4.5V to 18V Input and 0.6V to 8V Output

Large Image :  LTM4630AIY Integrated Circuit Chip DC/DC μModule Regulator with 36A Output 4.5V to 18V Input and 0.6V to 8V Output

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LTM4630AIY
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: BGA-144
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

LTM4630AIY Integrated Circuit Chip DC/DC μModule Regulator with 36A Output 4.5V to 18V Input and 0.6V to 8V Output

Description
Part Number: LTM4630AIY Number Of Outputs: 1
Current - Output (Max): 36A Voltage - Input (Min): 4.5V
Operating Temperature: -40°C ~ 125°C Type: Non-Isolated PoL Module, Digital
Highlight:

36A Output Integrated Circuit Chip

,

4.5V to 18V Input DC/DC μModule Regulator

,

0.6V to 8V Output LTM4630AIY

LTM4630 Integrated Circuit Chip Dual 18A Or Single 36A Step-Down DC/DC μModule Regulator
Product Overview Of LTM4630

The LTM4630 is a dual 18A or single 36A output switching mode step-down DC/DC μModule® (micromodule) regulator. This complete power management solution includes switching controllers, power FETs, inductors, and all supporting components within a single package.

Operating from an input voltage range of 4.5V to 18V, the LTM4630 supports two outputs each with an output voltage range of 0.6V to 8V, set by a single external resistor. The high efficiency design delivers up to 18A continuous current for each output, requiring only minimal external input and output capacitors.

Specifications Of LTM4630
Type Non-Isolated PoL Module, Digital
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 15V
Voltage - Output 1 0.6 ~ 5.3V
Current - Output (Max) 36A
Features OCP, OVP
Operating Temperature -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 144-BBGA Module
Size / Dimension 0.63" L x 0.63" W x 0.20" H (16.0mm x 16.0mm x 5.0mm)
Supplier Device Package 144-BGA (16x16)
Key Features Of LTM4630
  • Dual 18A or Single 36A Output
  • Input Voltage Range: 4.5V to 18V
  • Output Voltage Range: 0.6V to 8V
  • ±1.5% Maximum Total DC Output Error Over Line, Load and Temperature
  • Higher Light Load Efficiency and Wider VOUT Range Than LTM4630
  • Differential Remote Sense Amplifier
  • Current Mode Control/Fast Transient Response
  • Multiphase Parallel Current Sharing Up to 144A
  • Internal Temperature Monitor
  • Adjustable Switching Frequency or Synchronization
  • Overcurrent Foldback Protection
  • Selectable Burst Mode® Operation, Pulse Skipping Mode Operation
  • Soft-Start/Voltage Tracking
  • Output Overvoltage Protection
Applications Of LTM4630
  • Telecom and Networking Equipment
  • Storage and ATCA Cards
  • Industrial Equipment
Related Components In Stock
Component Package
LTC2368IDE-24 DFN-16
LTC2372CUH-16 QFN-32
LTC2372HUH-16 QFN-32
MAX11158EUB μMAX-10
LTC2348ILX-18 LQFP-48
ADUM7802-8BRIZ SOIC-8
AD4883BBCZ CSPBGA-196
ADUM7812-8BRIZ SOIC-8
MAX11254ATJ TQFN-32
ADE7923ARWZ SOIC-20
AD7405BRIZ SOIC-16
MAX11262EUB µMAX-10
MAX11169EUB µMAX-10
MAX11901ETP TQFN-20
AD7981HRMZ MSOP-10
AD8285WBCPZ LFCSP-72
MAX11168EUB uMAX-10
MAX11905ETP TQFN-20
AD7902BRQZ QSOP-20
MAX11162EUB uMAX-10
AD7903BRQZ QSOP-20
LTC2377CDE-20 DFN-16
LTC2159CUK QFN-48
LTC2159IUK QFN-48
LTC2201CUK QFN-48
LTC2188CUP QFN-64
LTC2201IUK QFN-48
LTC2188IUP QFN-64
MAX11121ATI TQFN-28
MAX11122ATI TQFN-28
Product Tags

LTM4630AIY, LTM4630AI, LTM4630A, LTM4630

Frequently Asked Questions
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample? Is the sample free?
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
