Q48SC12042NRAH 500W DC/DC Power Module Integrated Circuit Chip with 95% Efficiency 1.5kV Isolation

The Q48SC12042 is a quarter-brick, 36–75 V input, single 12 V output, full digital control DC/DC converter. It provides up to 500 watts of power from a 36–75 V input in an industry-standard, DOSA-compliant footprint and pinout.

The Q48SC12042 achieves more than 95.0% efficiency at 48 V input, 12 V output and 42 A load. A built-in digital PWM controller in the Q48SC12042 series completes the Vo feedback, PWM signal generation, droop current sharing, fault protection, output voltage trim, on/off control and PMBUS communications, among other functions. Digital control delivers greater design and application flexibility along with advanced performance and reliability.

• Input voltage range: 36 V to 75 V
• Output voltage range (trim and PMBUS): 8 V to 13.2 V
• Fully regulated from 36 V to 75 V input
• High efficiency: 95.0% @ 48 Vin / 42 A
• Size: 58.4 mm × 36.8 mm × 12.4 mm (2.3" × 1.45" × 0.49")
• Industry-standard DOSA-compliant pinout
• Fully protected: input UVLO, output OCP and OVP, OTP
• Droop current sharing
• 1500 V isolation
• No minimum load required
• Fixed frequency operation

• Datacom / Networking
• Wireless networks
• Optical network equipment
• Server and data storage
• Industrial / Test equipment
