Large Image : AD7417ARZ Integrated Circuit Chip 10-Bit Digital Temperature Sensor And Four Channel ADC

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	AD7417ARZ

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	16-SOIC
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

AD7417ARZ Integrated Circuit Chip 10-Bit Digital Temperature Sensor And Four Channel ADC

Description

Part Number:	AD7417ARZ	Sensing Temperature - Local:	-40°C ~ 125°C
Output Type:	I2C	Voltage - Supply:	2.7V ~ 5.5V
Resolution:	10 B	Accuracy - Highest (Lowest):	±2°C (±3°C)
Highlight:	10-Bit Integrated Circuit Chip , I2C Digital Temperature Sensor , Four Channel ADC

AD7417ARZ Integrated Circuit Chip 10-Bit Digital Temperature Sensor And Four Channel ADC

Product Description Of AD7417

The AD7417 is a 10-bit, 4-channel and single-channel analog-to-digital converter (ADC) with an on-chip temperature sensor that operates from a single 2.7 V to 5.5 V power supply. The device contains a 15 µs successive approximation converter, a 5-channel multiplexer, a temperature sensor, a clock oscillator, a track-and-hold circuit, and a 2.5 V reference.

Specifications Of AD7417

Output Type	Digital
Accuracy	±2°C
Minimum Operating Temperature	−40°C
Maximum Operating Temperature	+125°C
Package / Case	SOIC-16
Interface Type	Serial
Supply Voltage – Min	2.7 V
Supply Voltage – Max	5.5 V
Configuration	Local
Resolution	10 bit
Operating Supply Current	600 µA
Unit Weight	331 mg

Key Features Of AD7417

10-bit ADC with 15 µs and 30 µs conversion times
4 single-ended analog input channels
On-chip temperature sensor: −40°C to +125°C
On-chip track-and-hold
Overtemperature indicator
Automatic power-down at the end of a conversion
Wide operating supply range: 2.7 V to 5.5 V
I²C-compatible serial interface
Selectable serial bus address allows connection of up to 8 AD7416/AD7417 devices to a single bus

Product Highlights Of AD7417

The AD7417 features an on-chip temperature sensor that enables accurate ambient temperature measurement (±1°C at 25°C, ±2°C overtemperature). The measurable temperature range is −40°C to +125°C. An overtemperature indicator is implemented by performing a digital comparison of the ADC code for Channel 0 (temperature sensor) with the contents of the on-chip T_OTI setpoint register.

The AD7417 offers a space-saving, 10-bit analog-to-digital solution with four external voltage input channels, an on-chip temperature sensor, an on-chip reference, and a clock oscillator.

The automatic power-down feature enables the AD7417 to achieve superior power performance. At slower throughput rates, the device can be programmed to operate in a low-power shutdown mode, allowing further savings in power consumption.

Applications Of AD7417

Data acquisition with ambient temperature monitoring
Industrial process control
Automotive
Battery-charging applications
Personal computers
