SMP1330-085LF Integrated Circuit Chip Low-Capacitance Silicon PIN Limiter Diode In QFN-3 Package

Description

Part Number:	SMP1330-085LF	Voltage - Peak Reverse (Max):	50V
Current - Max:	200 MA	Capacitance @ Vr, F:	1pF @ 0V, 1MHz
Resistance @ If, F:	2Ohm @ 10mA, 100MHz	Power Dissipation (Max):	3 W
Highlight:	Low-Capacitance PIN Limiter Diode , QFN-3 Package Silicon PIN Diode , Silicon RF Limiter Diode

SMP1330-085LF Integrated Circuit Chip Low-Capacitance Silicon PIN Limiter Diode In QFN-3 Package

Product Description Of SMP1330

The SMP1330 is a surface-mountable, low-capacitance silicon PIN limiter diode designed as a shunt-connected PIN diode for high-power limiter applications up to 6 GHz.

Maximum resistance at 10 mA is 2 Ω and maximum capacitance at 0 V is 0.55 pF. The combination of low junction capacitance, low parasitic inductance, low thermal resistance, and nominal 2 μm I-region width makes the SMP1330-085LF useful in large-signal limiter applications. The threshold level is +9 dBm at 1 GHz.

Specifications Of SMP1330

Parameter	Value
V_R — Reverse Voltage	50 V
Maximum Diode Capacitance	1 pF
Maximum Series Resistance @ Maximum I_F	2 Ohms
Minimum Operating Temperature	−40 °C
Maximum Operating Temperature	+150 °C
Minimum Operating Frequency	10 MHz
Maximum Operating Frequency	6 GHz
Carrier Life	4 ns
Maximum Series Resistance @ Minimum I_F	2 Ohms
P_d — Power Dissipation	3 W
Unit Weight	325.667 mg

Key Features Of SMP1330

Low thermal resistance: 91 °C/W
Typical threshold level: +9 dBm
Low capacitance: 0.55 pF
Low-profile, ultra-miniature QFN package (3-pin, 2 × 2 mm), MSL1 rated at 260 °C per JEDEC J-STD-020

Applications Of SMP1330

Low-loss, high-power limiters
Receiver protectors

Product Tags
