SX1278IMLTRT Integrated Circuit Chip IC Chip 137MHz To 525MHz Long Range Low Power Transceiver

The SX1278 transceiver features the LoRa® long-range modem, providing ultra-long-range spread-spectrum communication and high interference immunity while minimizing current consumption.

Using the patented LoRa modulation technique, the SX1278 achieves a sensitivity of over −148 dBm with a low-cost crystal and bill of materials. This high sensitivity, combined with the integrated +20 dBm power amplifier, yields an industry-leading link budget, making it optimal for any application requiring range or robustness. LoRa also provides significant advantages in both blocking and selectivity over conventional modulation techniques, solving the traditional design compromise between range, interference immunity, and energy consumption.

• LoRa™ Modem with 168 dB maximum link budget
• +20 dBm – 100 mW constant RF output vs. V supply
• +14 dBm high-efficiency PA
• Programmable bit rate up to 300 kbps
• High sensitivity: down to −148 dBm
• Bullet-proof front end: IIP3 = −11 dBm
• Excellent blocking immunity
• Low RX current of 9.9 mA, 200 nA register retention
• Fully integrated synthesizer with a resolution of 61 Hz
• FSK, GFSK, MSK, GMSK, LoRa, and OOK modulation
• Built-in bit synchronizer for clock recovery
• Preamble detection
• 127 dB dynamic range RSSI
• Automatic RF Sense and CAD with ultra-fast AFC
• Packet engine up to 256 bytes with CRC
• Built-in temperature sensor and low battery indicator

• Automated Meter Reading
• Home and Building Automation
• Wireless Alarm and Security Systems
• Industrial Monitoring and Control
• Long-range Irrigation Systems

• SX1278IMLTRT
• SX1278IMLTR
• SX1278IMLT
• SX1278IML
• SX1278IM
• SX1278I
• SX1278
