V48SD12005NNFA Integrated Circuit Chip 60W 1/16th Brick DCDC Power Module

V48SD12005NNFA Integrated Circuit Chip 60W 1/16th Brick DCDC Power Module
V48SD12005NNFA Integrated Circuit Chip 60W 1/16th Brick DCDC Power Module

Large Image :  V48SD12005NNFA Integrated Circuit Chip 60W 1/16th Brick DCDC Power Module

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: V48SD12005NNFA
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: MODULE
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

V48SD12005NNFA Integrated Circuit Chip 60W 1/16th Brick DCDC Power Module

Description
Part Number: V48SD12005NNFA Output Power:: 60 W
Output Voltage-Channel 1:: 12 V Output Current-Channel 1:: 5 A
Isolation Voltage:: 2.25 KV Input Voltage:: 36 V To 60 V
Highlight:

60W DC-DC Power Module

,

12V Output Integrated Circuit Chip

,

1/16th Brick Isolated DC-DC Converter

V48SD12005NNFA Integrated Circuit Chip 60W 1/16th Brick DCDC Power Module
Product Overview Of V48SD12005

The V48SD12005 is a 1/16-brick isolated DC-DC power supply module designed for high-density, high-reliability applications. It accepts an input voltage range of 36–60 V (suitable for a 48 V communication bus) and delivers a regulated output of 12 V / 5 A with a rated power of 60 W. Typical efficiency is 92.2%, and the module provides an isolation withstand voltage of 2,250 Vdc.

The module supports negative-logic remote enable and pre-biased start-up. It features a comprehensive set of built-in protection circuits for under-voltage, over-current, over-voltage, and over-temperature conditions, with fixed-frequency switching and high power density.

Specifications Of V48SD12005
IsolationIsolated
Number of Outputs1 Output
Output Power60 W
Output Voltage — Channel 112 V
Output Current — Channel 15 A
Isolation Voltage2.25 kV
Length33 mm (1.299 in)
Width22.8 mm (0.898 in)
Height8.8 mm (0.346 in)
IndustryIndustrial
Maximum Operating Temperature+ 85 °C
Minimum Operating Temperature− 40 °C
Input Voltage36 V to 60 V
Unit Weight12.300 g
Key Features Of V48SD12005
  • High efficiency: 93.5% at full load
  • Fixed frequency operation
  • Input UVLO, OTP and output OCP, OVP
  • Output voltage trim: max 20%
  • Pre-biased startup
  • 2250 V isolation and basic insulation
  • Applied to altitude up to 5000 m
Applications Of V48SD12005
  • Telecommunications equipment, network switches, routers
  • Servers, data storage, on-board power supply for data centres
  • Industrial embedded devices, secondary step-down power supply for 48 V bus systems
