IXTH200N10T 100V 200A N-Channel Power MOSFET Trench Gate MOSFET TO-247-3 Integrated Circuit Chip

IXTH200N10T 100V 200A N-Channel Power MOSFET Trench Gate MOSFET TO-247-3 Integrated Circuit Chip
IXTH200N10T 100V 200A N-Channel Power MOSFET Trench Gate MOSFET TO-247-3 Integrated Circuit Chip

Large Image :  IXTH200N10T 100V 200A N-Channel Power MOSFET Trench Gate MOSFET TO-247-3 Integrated Circuit Chip

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IXTH200N10T
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TO-247-3
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 10000 Pieces per Day
Contact Now

IXTH200N10T 100V 200A N-Channel Power MOSFET Trench Gate MOSFET TO-247-3 Integrated Circuit Chip

Description
Part Number: IXTH200N10T FET Type: N-Channel
Drain To Source Voltage (Vdss): 100 V Current - Continuous Drain (Id) @ 25°C: 200A (Tc)
Input Capacitance (Ciss) (Max) @ Vds: 9400 PF @ 25 V Power Dissipation (Max): 550W (Tc)
Highlight:

100V Power MOSFET

,

200A N-Channel MOSFET

,

TO-247-3 Trench Gate MOSFET

IXTH200N10T Integrated Circuit Chip 100V 200A N-Channel Trench Gate Power MOSFETs TO-247-3



Product Overview Of IXTH200

The IXTH200N10T is a 100V, 200A N-Channel Enhancement Mode Trench Gate Power MOSFET housed in a TO-247-3 package. It belongs to a series of high-current, low-on-resistance trench-gate power MOSFETs designed for demanding power switching applications, including switch-mode power supplies, motor drives, inverters, DC-DC converters, and welding machines.

Specifications Of IXTH200
Product Category MOSFETs
Technology Si
Mounting Style Through Hole
Package / Case TO-247-3
Transistor Polarity N-Channel
Number of Channels 1 Channel
Vds – Drain-Source Breakdown Voltage 100 V
Id – Continuous Drain Current 200 A
Rds On – Drain-Source Resistance 5.5 mΩ
Minimum Operating Temperature −55 °C
Maximum Operating Temperature +175 °C
Pd – Power Dissipation 550 W
Channel Mode Enhancement
Tradename HiPerFET
Fall Time 34 ns
Product Type MOSFETs
Rise Time 31 ns
Transistor Type 1 N-Channel
Typical Turn-Off Delay Time 45 ns
Typical Turn-On Delay Time 35 ns
Key Features Of IXTH200
  • 175 °C operating temperature
  • Low RDS(ON)
  • Avalanche rated
  • High current handling capability
  • Fast intrinsic rectifier
Applications Of IXTH200
  • Automotive
    • Motor drives
    • High-side switch
    • 12V battery
    • ABS systems
  • DC/DC converters and off-line UPS
    • Primary-side switch
  • High current switching applications
