ADUM1401ARWZ 2500Vrms Quad-Channel Digital Isolator Integrated Circuit Chip SOIC-16 for Industrial Isolation

ADUM1401ARWZ Integrated Circuit Chip 2500Vrms Quad-Channel Digital Isolator SOIC-16

The ADUM1401ARWZ is a quad-channel digital isolator that provides four independent isolation channels in a variety of channel configurations and data rates. It operates with supply voltages on either side ranging from 2.7 V to 5.5 V, offering compatibility with lower-voltage systems and enabling voltage translation functionality across the isolation barrier.

• Low power operation
• 5 V operation: 1.0 mA per channel maximum at 0 Mbps to 2 Mbps; 3.5 mA per channel maximum at 10 Mbps; 31 mA per channel maximum at 90 Mbps
• 3 V operation: 0.7 mA per channel maximum at 0 Mbps to 2 Mbps; 2.1 mA per channel maximum at 10 Mbps; 20 mA per channel maximum at 90 Mbps
• Bidirectional communication
• 3 V/5 V level translation
• High temperature operation: 125°C
• High data rate: dc to 90 Mbps (NRZ)
• Precise timing characteristics: 2 ns maximum pulse width distortion; 2 ns maximum channel-to-channel matching
• High common-mode transient immunity: >25 kV/µs
• Output enable function
• 16-lead SOIC wide body package

• General-purpose multichannel isolation
• SPI interface / data converter isolation
• RS-232 / RS-422 / RS-485 transceivers
• Industrial field bus isolation
• Automotive systems
