LTM4622EY Dual 2.5A Ultrathin BGA-25 DC/DC μModule Regulator Step-Down Voltage Regulator Integrated Circuit Chip with 3.6V to 20V Input Range

LTM4622EY Integrated Circuit Chip 2.5A Dual Ultrathin Step-Down DC/DC μModule Regulator BGA-25

The LTM4622 is a complete dual 2.5A step-down switching mode μModule® (power module) regulator housed in a compact 6.25mm × 6.25mm × 2.42mm BGA package. The package integrates the switching controller, power FETs, inductor, and all support components, delivering a fully integrated power solution.

Operating over an input voltage range of 3.6V to 20V, the LTM4622 supports an output voltage range of 0.6V to 5.5V, set by a single external resistor. Its high-efficiency design delivers dual 2.5A continuous (3A peak) output current. Only a few ceramic input and output capacitors are required for operation.

• Complete solution in less than 1 cm²
• Wide input voltage range: 3.6V to 20V
• 3.3V input compatible with VIN tied to INTV_CC
• 0.6V to 5.5V output voltage
• Dual 2.5A (3A peak) or single 5A output current
• ±1.5% maximum total output voltage regulation error over load, line, and temperature
• Current mode control with fast transient response
• External frequency synchronization
• Multiphase parallelable with current sharing
• Output voltage tracking and soft-start capability
• Selectable Burst Mode® operation
• Overvoltage input and overtemperature protection
• Power good indicators

• General purpose point-of-load conversion
• Telecom, networking, and industrial equipment
• Medical diagnostic equipment
• Test and debug systems
