Real Time Microcontrollers F280037CSPN 120MHz Microcontrollers Chip LQFP80

Real Time Microcontrollers F280037CSPN 120MHz Microcontrollers Chip LQFP80​

Product Description Of F280037CSPN

F280037CSPN 32-bit MCU 256KB flash Microcontrollers Chip, DSP core at 120 MHz, Ten hardware breakpoints (with ERAD). The Package is LQFP80​, Up to 23 external channels (includes the two gpdac outputs).

Specification Of F280037CSPN

Features Of F280037CSPN

• Programmable Control Law Accelerator (CLA) 120 MHz
• One Controller Area Network with Flexible Data-Rate (CAN FD/MCAN) bus port
• Three 4-MSPS, 12-bit Analog-to-Digital Converters (ADCs)
• Two Serial Peripheral Interface (SPI) ports
• Three Enhanced Capture (eCAP) modules
• Embedded Pattern Generator (EPG)
• High-resolution Capture (HRCAP) available on one of the three eCAP modules
• Temperature options - Junction (TJ): –40°C to 150°C
• Access to internal memory from an external host
• One Power-Management Bus (PMBus) interface

Applications Of F280037CSPN

• Infotainment and cluster
• Head-up display
• Automotive head unit
• Automotive external amplifier
