80MHz Microcontroller MCU STM32L475VET6TR 32-Bit Microcontroller IC 100-LQFP

80MHz Microcontroller MCU STM32L475VET6TR 32-Bit Microcontroller IC 100-LQFP

Product Description Of STM32L475VET6TR

STM32L475VET6TR is the ultra-low-power microcontrollers based on the highperformance Arm® Cortex®-M4 32-bit RISC core operating at a frequency of up to 80 MHz. The Cortex-M4 core features a Floating point unit (FPU) single precision which supports all Arm® single-precision data-processing instructions and data types.

Specification Of STM32L475VET6TR

Feature Of STM32L475VET6TR

• Ultra-low-power with FlexPowerControl
• 1.71 V to 3.6 V power supply
• -40 °C to 85/105/125 °C temperature range
• 300 nA in VBAT mode: supply for RTC and 32x32-bit backup registers
• 30 nA Shutdown mode (5 wakeup pins)
• 120 nA Standby mode (5 wakeup pins)
• 420 nA Standby mode with RTC
• 1.1 µA Stop 2 mode, 1.4 µA with RTC
• 100 µA/MHz run mode
• Batch acquisition mode (BAM)
• 4 µs wakeup from Stop mode
• Brown out reset (BOR)
• Interconnect matrix
