STM32L011F3U3TR 32-Bit Single-Core 32MHz ARM Cortex-M0+ Microcontroller IC

  STM32L011F3U3TR 32-Bit Single-Core 32MHz ARM Cortex-M0+ Microcontroller IC

Product Description Of STM32L011F3U3TR

STM32L011F3U3TR incorporates the high-performance Arm® Cortex®-M0+ 32-bit RISC core operating at a 32 MHz frequency, high-speed embedded memories (up to 16 Kbytes of Flash program memory, 512 bytes of data EEPROM and 2 Kbytes of RAM) plus an extensive range of enhanced I/Os and peripherals.

Specification Of STM32L011F3U3TR

Features Of STM32L011F3U3TR

• 1.65 V to 3.6 V power supply

• -40 to 125 °C temperature range

• 0.23 µA Standby mode (2 wakeup pins)

• 0.29 µA Stop mode (16 wakeup lines)

• 0.54 µA Stop mode + RTC + 2 KB RAMretention

• Down to 76 µA/MHz in Run mode

• 5 µs wakeup time (from Flash memory)

• 41 µA 12-bit ADC conversion at 10 ksps

• Ultra-safe, low-power BOR (brownout reset) with 5 selectable thresholds

• Ultralow power POR/PDR

• Programmable voltage detector (PVD)

• 0 to 32 MHz external clock

• 32 kHz oscillator for RTC with calibration

• High speed internal 16 MHz factory-trimmed RC (+/- 1%)

• Internal low-power 37 kHz RC

• Internal multispeed low-power 65 kHz to 4.2 MHz RC– PLL for CPU clock

• Up to 16 KB Flash memory with ECC

• 2 KB RAM

• 512 B of data EEPROM with ECC

• 20-byte backup register

• Sector protection against R/W operation
