CC2640R2FTRGZRQ1 32-bit Arm Cortex-M3 BT 5.1 Low Energy Wireless MCU With 128KB Flash

CC2640R2FTRGZRQ1 32-bit Arm Cortex-M3 BT 5.1 Low Energy Wireless MCU With 128KB Flash

Product Description Of CC2640R2FTRGZRQ1

CC2640R2FTRGZRQ1 device is a 2.4 GHz wireless microcontroller (MCU) supporting BT 5.1 Low Energy and Proprietary 2.4 GHz applications. The device is optimized for low-power wireless communication and advanced sensing in building security systems, HVAC, asset tracking, and medical markets, and applications where industrial performance is required.

Specification Of CC2640R2FTRGZRQ1

Feature Of CC2640R2FTRGZRQ1

• Powerful Arm Cortex-M3

• EEMBC CoreMark score: 142

• Up to 48-MHz clock speed

• 275KB of nonvolatile memory including 128KB of in-system Programmable Flash

• Up to 28KB of system SRAM, of which 20KB is ultra-low leakage SRAM

• 8KB of SRAM for cache or system RAM use

• 2-Pin cJTAG and JTAG debugging

• Supports over-the-air upgrade (OTA)

• Can run autonomous from the rest of the system

• 16-bit architecture

• 2KB of ultra-low leakage SRAM for code and data

• All digital peripheral pins can be routed to any GPIO

• Four general-purpose timer modules (eight 16-bit or four 32-bit timers, PWM each)

• 12-bit ADC, 200-ksamples/s, 8-channel analog MUX

• Continuous time comparator

• Ultra-low power analog comparator

• Programmable current source

• UART, I2C, and I2S

• 2× SSI (SPI, MICROWIRE, TI)

• Real-Time Clock (RTC)

• AES-128 security module

• True Random Number Generator (TRNG)

• Support for eight capacitive-sensing buttons

• Integrated temperature sensor
