Product Description Of STM32F091RCH6TR

STM32F091RCH6TR microcontrollers incorporate the high-performance ARM®Cortex®-M0 32-bit RISC core operating at up to 48 MHz frequency, high-speed embedded memories (up to 256 Kbytes of Flash memory and 32 Kbytes of SRAM), and an extensive range of enhanced peripherals and I/Os. The device offers standard communication interfaces (two I2Cs, two SPIs/one I2S, one HDMI CEC and up to eight USARTs), one CAN, one 12-bit ADC, one 12-bit DAC with two channels, seven 16-bit timers, one 32-bit timer and an advanced-control PWM timer.

STM32F091RCH6TR microcontrollers operate in the -40 to +85 °C and -40 to +105 °C temperature ranges, from a 2.0 to 3.6 V power supply. A comprehensive set of power-saving modes allows the design of low-power applications.

Specification Of STM32F091RCH6TR

Features Of STM32F091RCH6TR

• Core: ARM®32-bit Cortex®-M0 CPU, frequency up to 48 MHz

• 128 to 256 Kbytes of Flash memory

• 32 Kbytes of SRAM with HW parity

• CRC calculation unit

• Reset and power management

• Digital & I/Os supply: VDD= 2.0 V to 3.6 V

• Analog supply: VDDA= VDDto 3.6 V

• Power-on/Power down reset (POR/PDR)

• Programmable voltage detector (PVD)

• Low power modes: Sleep, Stop, Standby

• VBATsupply for RTC and backup registers

• 4 to 32 MHz crystal oscillator

• 32 kHz oscillator for RTC with calibration

• Internal 8 MHz RC with x6 PLL option

• Internal 40 kHz RC oscillator

• Internal 48 MHz oscillator with automatic trimming based on ext. synchronization

• Up to 88 fast I/Os

• All mappable on external interrupt vectors

• Up to 69 I/Os with 5V-tolerant capability and 19 with independent supply VDDIO2

• 12-channel DMA controller

• One 12-bit, 1.0 μs ADC (up to 16 channels)

• Conversion range: 0 to 3.6 V

• Separate analog supply: 2.4 V to 3.6 V

• One 12-bit D/A converter (with 2 channels)

• Two fast low-power analog comparators with programmable input and output

• Up to 24 capacitive sensing channels for touchkey, linear and rotary touch sensors

• Calendar RTC with alarm and periodic wakeup from Stop/Standby
