Product Description Of STM32L431VCI6

STM32L431VCI6 devices are the ultra-low-power microcontrollers based on the high-performance Arm® Cortex®-M4 32-bit RISC core operating at a frequency of up to 80 MHz. The Cortex-M4 core features a Floating point unit (FPU) single precision which supports all Arm® single-precision data-processing instructions and data types. It also implements a full set of DSP instructions and a memory protection unit (MPU) which enhances application security.

STM32L431VCI6 devices embed high-speed memories (Flash memory up to 256 Kbyte, 64 Kbyte of SRAM), a Quad SPI flash memories interface (available on all packages) and an extensive range of enhanced I/Os and peripherals connected to two APB buses, two AHB buses and a 32-bit multi-AHB bus matrix.

STM32L431VCI6 devices embed several protection mechanisms for embedded Flash memory and SRAM: readout protection, write protection, proprietary code readout protection and Firewall.

Specification Of STM32L431VCI6

Features Of STM32L431VCI6

• Ultra-low-power with FlexPowerControl

• 1.71 V to 3.6 V power supply

• -40 °C to 85/105/125 °C temperature range

• 200 nA in VBAT mode: supply for RTC and 32x32-bit backup registers

• 8 nA Shutdown mode (5 wakeup pins)

• 28 nA Standby mode (5 wakeup pins)

• 280 nA Standby mode with RTC

• 1.0 μA Stop 2 mode, 1.28 μA with RTC

• 84 μA/MHz run mode

• Batch acquisition mode (BAM)

• 4 μs wakeup from Stop mode

• Brown out reset (BOR)

• Interconnect matrix

• Core: Arm® 32-bit Cortex®-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator™) allowing 0-wait-state execution from Flash memory, frequency up to 80 MHz, MPU, 100DMIPS and DSP instructions

• Performance benchmark

• 1.25 DMIPS/MHz (Drystone 2.1)

• 273.55 CoreMark® (3.42 CoreMark/MHz @ 80 MHz)

• Energy benchmark

• 176.7 ULPBench® score

• Clock Sources

• 4 to 48 MHz crystal oscillator

• 32 kHz crystal oscillator for RTC (LSE)

• Internal 16 MHz factory-trimmed RC (±1%)

• Internal low-power 32 kHz RC (±5%)

• Internal multispeed 100 kHz to 48 MHz oscillator, auto-trimmed by LSE (better than ±0.25 % accuracy)

• Internal 48 MHz with clock recovery

• 2 PLLs for system clock, audio, ADC
