TMS320F28030PAGQ Microcontroller MCU Automotive 60MHz C2000™ 32-Bit MCU TQFP-64

TMS320F28030PAGQ Microcontroller MCU Automotive 60MHz C2000™ 32-Bit MCU TQFP-64

Product Description Of TMS320F28030PAGQ

C2000™ 32-bit microcontrollers are optimized for processing, sensing, and actuation to improve closed-loop performance in real-time control applications such as industrial motor drives; solar inverters and digital power; electrical vehicles and transportation; motor control; and sensing and signal processing. The C2000 line includes the Premium performance MCUs and the Entry performance MCUs.

TMS320F28030PAGQ microcontrollers provides the power of the C28x core and Control Law Accelerator (CLA) coupled with highly integrated control peripherals in low pin-count devices. This family is code-compatible with previous C28x-based code, and also provides a high level of analog integration.

Specification Of TMS320F28030PAGQ

Features Of TMS320F28030PAGQ

• High-efficiency 32-bit CPU

• 60MHz (16.67ns cycle time)

• 16 × 16 and 32 × 32 MAC operations

• 16 × 16 dual MAC

• Harvard bus architecture

• Atomic operations

• Fast interrupt response and processing

• Unified memory programming model

• Code-efficient (in C/C++ and Assembly)

• Programmable Control Law Accelerator (CLA)

• 32-bit floating-point math accelerator

• Executes code independently of the main CPU

• Endianness: Little endian

• JTAG boundary scan support

• IEEE Standard 1149.1-1990 Standard Test Access Port and Boundary Scan Architecture

• Single 3.3V supply

• No power sequencing requirement

• Integrated power-on reset and brown-out reset

• No analog support pins

• Two internal zero-pin oscillators

• On-chip crystal oscillator and external clock input

• Watchdog timer module

• Missing clock detection circuitry

• Up to 45 individually programmable, multiplexed GPIO pins with input filtering

• Peripheral Interrupt Expansion (PIE) block that supports all peripheral interrupts

• Three 32-bit CPU timers

• Independent 16-bit timer in each Enhanced Pulse Width Modulator (ePWM)

• On-chip memory

• Flash, SARAM, OTP, Boot ROM available

• Code-security module

• 128-bit security key and lock

• Protects secure memory blocks

• Prevents firmware reverse engineering

• Serial port peripherals

• One Serial Communications Interface (SCI) Universal Asynchronous Receiver/Transmitter (UART) module

• Two Serial Peripheral Interface (SPI) modules

• One Inter-Integrated-Circuit (I2C) module

• One Local Interconnect Network (LIN) module

• One Enhanced Controller Area Network (eCAN) module

• Enhanced control peripherals

• High-Resolution PWM (HRPWM)

• Enhanced Capture (eCAP) module

• High-Resolution Input Capture (HRCAP) module

• Enhanced Quadrature Encoder Pulse (eQEP) module

• Analog-to-Digital Converter (ADC)

• On-chip temperature sensor

• Comparator

• Advanced emulation features

• Analysis and breakpoint functions

• Real-time debug through hardware

Applications Of TMS320F28030PAGQ

• Air conditioner outdoor unit

• Door operator drive control

• DC/DC converter

• Inverter & motor control

• On-board (OBC) & wireless charger

• Automated sorting equipment

• Textile machine

• Welding machine

• AC charging (pile) station

• DC charging (pile) station

• EV charging station power module

• Wireless vehicle charging module

• Energy storage power conversion system (PCS)

• Micro inverter

• Solar power optimizer

• String inverter

• AC drive control module

• Linear motor segment controller

• Servo drive power stage module

• AC-input BLDC motor drive

• DC-input BLDC motor drive

• Industrial AC-DC

• Three phase UPS

• Merchant network & server PSU

• Merchant telecom rectifiers
