DSPIC33EP64MC204-I/PT Microcontroller MCU 16-Bit Digital Signal Controllers TQFP-44
Product Description Of DSPIC33EP64MC204-I/PT
DSPIC33EP64MC204-I/PT is 16-Bit digital signal controllers (DSCs), it features a 70MIPS dsPIC® DSC core with integrated DSP and enhanced on-chip peripherals.
DSPIC33EP64MC204-I/PT DSCs enable the design of high-performance, precision motor control systems that are more energy efficient, quieter in operation, have a great range and extended life. They can be used to control brushless DC, permanent magnet synchronous, AC induction and stepper motors.
Specification Of DSPIC33EP64MC204-I/PT
|
Series
|
dsPIC™ 33EP
|
|
Core Processor
|
|
|
Core Size
|
|
|
Speed
|
|
|
Connectivity
|
I2C, IrDA, LINbus, QEI, SPI, UART/USART
|
|
Peripherals
|
Brown-out Detect/Reset, DMA, Motor Control PWM, POR, PWM, WDT
|
|
Number of I/O
|
|
|
Program Memory Size
|
64KB (22K x 24)
|
|
Program Memory Type
|
|
|
RAM Size
|
|
|
Voltage - Supply (Vcc/Vdd)
|
|
|
Data Converters
|
|
|
Oscillator Type
|
|
|
Operating Temperature
|
|
|
Mounting Type
|
|
|
Supplier Device Package
|
|
|
Package / Case
|
|
Features Of DSPIC33EP64MC204-I/PT
Operating Conditions
3.0V to 3.6V, -40ºC to +85ºC, DC to 70 MIPS
3.0V to 3.6V, -40ºC to +150ºC, DC to 60 MIPS
dsPIC33E DSC Core
Modified Harvard Architecture
C Compiler Optimized Instruction Set
16-bit Wide Data Path
24-bit Wide Instructions
16x16 Integer Multiply Operations
32/16 and 16/16 Integer Divide Operations
Two 40-bit Accumulators with Rounding and Saturation Options
Single-Cycle Multiply and Accumulate
Single-Cycle shifts for up to 40-bit Data
16x16 Fractional Multiply/Divide Operations
High-Speed PWM
Up to three PWM pairs with independent timing
Dead time for rising and falling edges
7.14 ns PWM resolution
PWM support for Inverters, PFC, Lighting- BLDC, PMSM, ACIM, SRM
Programmable Fault inputs
Flexible trigger configurations for ADC conversions
Communication Interfaces
Two UART modules (15 Mbps)
Two 4-wire SPI modules (15 Mbps)
Two I2C™ modules (up to 1 Mbaud) with SMBus support
PPS to allow function remap
Programmable Cyclic Redundancy Check (CRC)
Direct Memory Access (DMA)
4-channel DMA with user-selectable priority arbitration
UART, SPI, ADC, IC, OC, and Timers
