MSP430F5152IRSBR Microcontroller MCU 16-Bit MCU 25MHz Mixed-Signal Microcontrollers

MSP430F5152IRSBR Microcontroller MCU 16-Bit MCU 25MHz Mixed-Signal Microcontrollers

Product Description Of MSP430F5152IRSBR

MSP430F5152IRSBR is 25MHz, 16-Bit Mixed-Signal microcontrollers with 16KB Flash, 2KB SRAM, 10-bit ADC, comparator, DMA, 16-bit High Resolution timer

MSP430F5152IRSBR features a powerful 16-bit RISC CPU, 16-bit registers, and constant generators that contribute to maximum code efficiency. The digitally controlled oscillator (DCO) allows the devices to wake up from low-power modes to active mode in less than 5 µs.

MSP430F5152IRSBR microcontrollers include two 16-bit high-resolution timers, two USCIs (USCI_A0 and USCI_B0), a 32-bit hardware multiplier, a high-performance 10-bit ADC, an on-chip comparator, a 3-channel DMA, 5-V tolerant I/Os, and up to 29 I/O pins.

Specification Of MSP430F5152IRSBR

Features Of MSP430F5152IRSBR

• Low Supply-Voltage Range: 3.6 V Down to 1.8 V
• Ultra-Low Power Consumption
– Active Mode (AM): 180 µA/MHz
– Standby Mode (LPM3 WDT Mode, 3 V): 1.1 µA
– Off Mode (LPM4 RAM Retention, 3 V): 0.9 µA
– Shutdown Mode (LPM4.5, 3 V): 0.25 µA
• Wake up From Standby Mode in Less Than 5 µs
• 16-Bit RISC Architecture, Extended Memory, 40-ns Instruction Cycle Time

• Flexible Power-Management System
– Fully Integrated LDO With Programmable Regulated Core Supply Voltage
– Supply Voltage Supervision, Monitoring, and Brownout
• Unified Clock System
– FLL Control Loop for Frequency Stabilization
– Low-Power Low-Frequency Internal Clock Source (VLO)
– Low-Frequency Trimmed Internal Reference Source (REFO)
– 32-kHz Crystals (XT1)
– High-Frequency Crystals up to 25 MHz (XT1)

• Hardware Multiplier Supports 32-Bit Operations
• 3-Channel DMA
• Up to Twelve 5-V-Tolerant Digital Push/Pull I/Os With up to 20-mA Drive Strength(1)
• 16-Bit Timer TD0 With Three Capture/Compare Registers and Support of High-Resolution Mode

Applications Of MSP430F5152IRSBR
• Analog and Digital Sensor Systems
• LED Lighting
• Digital Power Supplies
• Motor Controls
• Remote Controls
• Thermostats
