LPC54101J256UK49 Microcontroller MCU 100MHz 32-Bit Single-Core Microcontrollers

LPC54101J256UK49 Microcontroller MCU 100MHz 32-Bit Single-Core Microcontrollers​

Product Description Of LPC54101J256UK49

LPC54101J256UK49 is Low-Power Microcontrollers (MCUs) Based on Arm® Cortex®-M4 Cores With Optional Cortex®-M0+ Co-processor.

LPC54101J256UK49 is ARM Cortex-M4 based microcontrollers for embedded applications. The ARM Cortex-M4 is a 32-bit core that offers system enhancements such as low power consumption, enhanced debug features, and a high level of support block integration.

Specification Of LPC54101J256UK49

Features Of LPC54101J256UK49

On-chip memory:
- Up to 512 kB on-chip flash program memory with flash accelerator and 256byte page erase and write.
- 104 kB total SRAM composed of:
- Up to 96 kB contiguous main SRAM.
- An additional 8 kB SRAM.
Analog peripheral: 12-bit, 12-channel, Analog-to-Digital Converter (ADC) supporting 5.0 Msamples/s. The ADC supports two independent conversion sequences.
Single power supply 1.62 V to 3.6 V.
Power-On Reset (POR).
Brown-Out Detect (BOD) with separate thresholds for interrupt and forced reset.
JTAG boundary scan supported.
Unique device serial number (128 bit) for identification.
Operating temperature range 40 °C to 105 °C.
Available in a 3.288 x 3.288 mm WLCSP49 package
