Product Description Of ML610Q431-NNNTCZ03A

ML610Q431-NNNTCZ03A is 8-bit Microcontroller with a Built-in LCD driver.

ML610Q431-NNNTCZ03A——This LSI is a high-performance 8-bit CMOS microcontroller into which rich peripheral circuits, such as real-time clock, synchronous serial port, UART, I2C bus interface (master), melody driver, battery level detect circuit, RC oscillation type A/D converter, 12-bit successive approximation type A/D converter, and LCD driver, are incorporated around 8 bit CPU nX-U8/100.

ML610Q431-NNNTCZ03A——The CPU nX-U8/100 is capable of efficient instruction execution in 1-intruction 1-clock mode by 3-stage pipe line architecture parallel procesing. The Flash ROM that is installed as program memory achieves low-voltage low-power consumption operation (read operation) equivalent to mask ROM and is most suitable for battery-driven applications.

Features Of ML610Q431-NNNTCZ03A

• CPU
− 8-bit RISC CPU (CPU name: nX-U8/100)
− Instruction system: 16-bit instructions
− On-Chip debug function
− Minimum instruction execution time
30.5 µs (@32.768 kHz system clock)
0.24 4µs (@4.096 MHz system clock)
• Timers
− 8 bits × 4 channels (16-bit configuration available)
• 1 kHz timer
− 10 Hz/1 Hz interrupt function
• Capture
− Time base capture × 2 channels (4096 Hz to 32 Hz)
• PWM
− Resolution 16 bits × 1 channel
• I2C bus interface
− Master function only
− Fast mode (400 kbps@4MHｚ), standard mode (100 kbps@4MHz, 50kbps@500kHz)
• Successive approximation type A/D converter
− 12-bit A/D converter
− Input × 2 channels
• Guaranteed operating range
− Operating temperature: −20°C to 70°C
− Operating voltage: VDD = 1.1V to 3.6V, AVDD = 2.2V to 3.6V
