R5F100GEA101FB Microcontroller MCU RL78/G13 Low Power High Function Microcontrollers

R5F100GEA101FB Microcontroller MCU RL78/G13 Low Power High Function Microcontrollers

Product Description Of R5F100GEA101FB
R5F100GEA101FB RL78/G13 microcontrollers balance the industry's lowest level of consumption current (CPU: 66 μA/MHz, standby (STOP): 230 nA) and a high performance of 43.2 DMIPS (32 MHz). They have an on-chip oscillator, data flash, A/D converter, and more. Built-in safety features (function that detects illegal operation of hardware) enable support for the household appliance safety standard (IEC/UL 60730). These microcontrollers can be used in a wide variety of applications from home and consumer appliances to industrial equipment.

Feature Of R5F100GEA101FB
CPU: RL78 core, Max. 32MHz
Voltage: 1.6V to 5.5V
Package: 64-pin HTFQFP, 24 to 48-pin HWQFN, 48 to 128-pin LFQFP, 44 to 100-pin LQFP, 20 to 30-pin LSSOP, 64-pin VFBGA, 25 to 36-pin WFLGA
Memory: SRAM Max. 32KB, Program Flash Max. 512KB
Timer: 16-bit Timer (ch) x 8, 8-bit Timer (ch) x 8, Watchdog Timer (ch) x 1, Interval Timer x 1 ch
PWM: PWM Output x 7
Analog function: 10-bit A/D Converter (ch) x 9
On-chip Oscillator Freq. (MHz): High-Speed: 32, 24, 16, 12, 8, 4, 1MHz
Low-speed: 15kHz
Others: RTC, Power-On Reset, Low Voltage Detection

Applications Of R5F100GEA101FB
Smart Grid Fault Indicator Unit
Tankless Gas Water Heater with Remote Control
Smart Earbuds Case Charger
Household Water Pump
Bathroom Odor Detector
Air Duct System
Critical Power Monitoring System
Access Control with Body Temperature Measurement
Multi-Purpose Air Quality Sensor
Personal Safety Tracker with GPS, NFC, Air Quality Sensor
DTDS-622C LoRa Modem
Smart Water Purifier System
HVAC Environment Monitor Module for Public Buildings
Heat Pump Control System
DALI Solutions
Unified Speed Control Platform for BLDC Ceiling Fans
LoRaWAN Street Light Controller

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
