STM8L151R6T6 Microcontroller MCU 16MHz 8-Bit Microcontroller IC LQFP-64 Embedded MCU

STM8L151R6T6 Microcontroller MCU 16MHz 8-Bit Microcontroller IC LQFP-64 Embedded MCU​

Product Description Of STM8L151R6T6

STM8L151R6T6 is 16MHz, 8-Bit EnergyLite Microcontroller IC. STM8L151R6T6 feature an enhanced STM8 CPU core providing increased processing power (up to 16 MIPS at 16 MHz) while maintaining the advantages of a CISC architecture with improved code density, a 24-bit linear addressing space and an optimized architecture for low-power operations.

Specification Of STM8L151R6T6

Features Of STM8L151R6T6

• Operating conditions
– Operating power supply: 1.65 to 3.6 V (without BOR), 1.8 to 3.6 V (with BOR)
– Temp. range: -40 to 85, 105 or 125 °C
• Low-power features
– 5 low-power modes: Wait, Low-power run (5.9 µA), Low power wait (3 µA), Activehalt with full RTC (1.4 µA), Halt (400nA)
– Consumption: 200 µA/MHz+330 µA
– Fast wake up from Halt mode (4.7 µs)
– Ultra low leakage per I/0: 50 nA
• Advanced STM8 core
– Harvard architecture and 3-stage pipeline
– Max freq: 16 MHz, 16 CISC MIPS peak
– Up to 40 external interrupt sources
• 2x12-bit DAC (dual mode) with output buffer
• 12-bit ADC up to 1 Msps/28 channels
• Communication interfaces
– Two synchronous serial interface (SPI)
– Fast I2C 400 kHz SMBus and PMBus
– Three USARTs (ISO 7816 interface + IrDA)
• Up to 67 I/Os, all mappable on interrupt vectors
