ATSAMD51N19A-AU Microcontroller MCU 120MHz 32-Bit ARM Cortex-M4F MCU TQFP-100 Package

ATSAMD51N19A-AU Microcontroller MCU 120MHz 32-Bit ARM Cortex-M4F MCU TQFP-100 Package

Product Description Of ATSAMD51N19A-AU
ATSAMD51N19A-AU high performance micro-controller is targeted for general purpose applications using the 32-bit ARM® Cortex®-M4 processor with Floating Point Unit (FPU), running up to 120 MHz ,up to 1 MB Dual Panel Flash with ECC, and up to 256 KB of SRAM with ECC .

ATSAMD51N19A-AU offers excellent features with class leading power performance ideal for multiple market segments.

Specification Of ATSAMD51N19A-AU

Feature Of ATSAMD51N19A-AU
ARM Cortex-M4F CPU running at up to 120 MHz
Floating Point Unit (FPU)
Embedded Trace Module (ETM) with instruction trace stream
Core Sight Embedded Trace Buffer (ETB)
Error Correction Code (ECC)
Dual bank with Read-While-Write (RWW) support
EEPROM hardware emulation
Error Correction Code (ECC) RAM option
Up to 4 KB of Tightly Coupled Memory (TCM)
Up to 8 KB additional SRAM with backup retention capability
Power-on Reset (POR) and Brown-out detection (BOD)
Internal and external clock options
External Interrupt Controller (EIC)
Two-pin Serial Wire Debug (SWD) programming, test, and debugging interface
Five Low Power Modes (Idle, Standby, Hibernate, Backup, and Off )
Sleep Walking peripherals.
Battery backup support
Embedded Buck/LDO regulator supporting on-the-fly selection.
65µA/MHz active power consumption.
Five confidential modes of operation (ECB, CBC, CFB, OFB, CTR)
True Random Number Generator (TRNG)
Elliptic Curves Cryptography (ECC) ECC GF(2n), ECC GF(p)
Integrity Check Module (ICM) based on Secure Hash Algorithm (SHA1, SHA224, SHA256), DMA
32-channel Direct Memory Access Controller (DMAC)
Compatibility with SD and SDHC Memory Card Specification Version 3.01
Compatibility with SDIO Specification Version 3.0
Compliant with JDEC specification, MMC memory cards V4.51
eXecute-In-Place (XIP) support
Up to 75 MHz SDR operation and DDR support
Embedded host and device function
USART with full-duplex and single-wire half-duplex configuration
One two-channel Inter-IC Sound Interface (I2S)
Up to 14-bit parallel capture mode
Up to 256 channel capacitive touch and proximity sensing
32-channel Event System
16-bit ,32-bit or 8-bit TC with two compare/capture channels
Two 24-bit Timer/Counters for Control (TCC), with extended functions:
Up to 5 wake-up pins with tamper detection and de-bouncing filter
Watchdog Timer (WDT) with Window mode
CRC-32 generator
Position Decoder (PDEC)
Frequency meter (FREQM)
One Configurable Custom Logic (CCL)
Differential and single-ended input
Automatic offset and gain error compensation
Oversampling and decimation in hardware to support 13-, 14-, 15-, or 16-bit resolution
Dual 12-bit, 1 MSPS Output Digital-to-Analog Converter (DAC)
Two Analog Comparators (AC) with Window Compare function
One temperature sensor
81 programmable I/O pins
