STM32F100C4T6A Microcontroller MCU High-Performance Mainstream Arm Cortex-M3 32-Bit MCU

STM32F100C4T6A Microcontroller MCU High-Performance Mainstream Arm Cortex-M3 32-Bit MCU

Product Description Of STM32F100C4T6A
STM32F100C4T6A microcontrollers incorporate the high-performance ARM®Cortex®-M3 32-bit RISC core operating at a 24 MHz frequency, high-speed embedded memories (Flash memory up to 128 Kbytes and SRAM up to 8 Kbytes), and an extensive range of enhanced peripherals and I/Os connected to two APB buses. All devices offer standard communication interfaces (up to two I2Cs, two SPIs, one HDMI CEC, and up to three USARTs), one 12-bit ADC, two 12-bit DACs, up to six general-purpose 16-bit timers and an advanced-control PWM timer.

Feature Of STM32F100C4T6A
Core: ARM®32-bit Cortex®-M3 CPU
24 MHz maximum frequency,1.25 DMIPS/MHz (Dhrystone 2.1) performance
Single-cycle multiplication and hardware division
16 to 128 Kbytes of Flash memory
4 to 8 Kbytes of SRAM
Clock, reset and supply management
2.0 to 3.6 V application supply and I/Os
POR, PDR and programmable voltage detector (PVD)
4-to-24 MHz crystal oscillator
Internal 8 MHz factory-trimmed RC
Internal 40 kHz RC
PLL for CPU clock
32 kHz oscillator for RTC with calibration
Sleep, Stop and Standby modes
VBATsupply for RTC and backup registers
Debug mode
Serial wire debug (SWD) and JTAG interfaces
7-channel DMA controller
Peripherals supported: timers, ADC, SPIs, I2Cs, USARTs and DACs
1 × 12-bit, 1.2 μs A/D converter (up to 16 channels)
Conversion range: 0 to 3.6 V
Temperature sensor
2 × 12-bit D/A converters
Up to 80 fast I/O ports
37/51/80 I/Os, all mappable on 16 external interrupt vectors and almost all 5 V-tolerant
Up to 12 timers
Up to three 16-bit timers, each with up to 4 IC/OC/PWM or pulse counter
16-bit, 6-channel advanced-control timer: up to 6 channels for PWM output, dead time generation and emergency stop
One 16-bit timer, with 2 IC/OC, 1 OCN/PWM, dead-time generation and emergency stop
Two 16-bit timers, each with IC/OC/OCN/PWM, dead-time generation and emergency stop
2 watchdog timers (Independent and Window)
SysTick timer: 24-bit downcounter
Two 16-bit basic timers to drive the DAC
Up to 8 communications interfaces

Applications Of STM32F100C4T6A
Application control and user interfaces
Medical and hand-held equipment
PC and gaming peripherals
GPS platforms
Industrial applications
PLCs
Inverters
Printers
Scanners
Alarm systems
Video intercoms
HVACs
