Product Description Of LPC54114J256UK49

LPC54114J256UK49 is ARM Cortex-M4 based microcontrollers for embedded applications. It include an ARM Cortex-M0+ coprocessor, up to 192 KB of on-chip SRAM, up to 256 KB on-chip flash, full-speed USB device interface with Crystal-less operation, a DMIC subsystem with PDM microphone interface and I2S, five general-purpose timers, one SCTimer/PWM, one RTC/alarm timer, one 24-bit Multi-Rate Timer (MRT), a Windowed Watchdog Timer (WWDT), eight flexible serial communication peripherals (each of which can be a USART, SPI, or I2C interface), and one 12-bit 5.0 Msamples/sec ADC, and a temperature sensor.

Specification Of LPC54114J256UK49

Features Of LPC54114J256UK49

Dual processor cores: ARM Cortex-M4 and ARM Cortex-M0+. Both cores operate up to a maximum frequency of 150 MHz.
On-chip memory:
- Up to 256 KB on-chip flash program memory with flash accelerator and 256 byte page erase and write.
- Up to 192 KB total SRAM consisting of 160 KB contiguous main SRAM and an additional 32 KB SRAM on the I&D buses.
Analog peripherals
- 12-bit ADC with 12 input channels and with multiple internal and external trigger inputs and sample rates of up to 5.0 MSamples/sec. The ADC supports two independent conversion sequences.
- Integrated temperature sensor connected to the ADC.
Single power supply 1.62 V to 3.6 V.
JTAG boundary scan supported.
128 bit unique device serial number for identification.
Operating temperature range 40 °C to +105 °C.

Applications Of LPC54114J256UK49
Automotive
- Heating Ventilation and Air Conditioning (HVAC)
- Motorcycle Engine Control Unit (ECU) and Small Engine Control
- Smart Car Access
Consumer
- Air Conditioning (AC)
- Hearables
- Major Home Appliances
- Robotic Appliance
- Small and Medium Appliances
Industrial
- Automatic Vehicle Identification
- Heat Meter
- Industrial HMI
- Motion Control and Robotics
- POS Terminal
- Power Grid Converter
- Smart Power Socket
- Smart Watch and Wristband
