STM8S105K4T6C Microcontroller MCU 8-Bit Microcontroller IC 16MHz Embedded MCU LQFP32

STM8S105K4T6C Microcontroller MCU 8-Bit Microcontroller IC 16MHz Embedded MCU LQFP32

Product Description Of STM8S105K4T6C

STM8S105K4T6C access line 8-bit microcontrollers offer from 16 to 32 Kbyte Flash program memory, plus integrated true data EEPROM.
STM8S105K4T6C performance is ensured by a 16 MHz CPU clock frequency and enhanced characteristics which include robust I/O, independent watchdogs (with a separate clock source), and a clock security system.

Specification Of STM8S105K4T6C

Features Of STM8S105K4T6C
Core
- 16 MHz advanced STM8 core with Harvard architecture and 3-stage pipeline
- Extended instruction set
Memories
- Program memory: up to 32 Kbyte Flash; data retention 20 years at 55 °C after 10 kcycle
- Data memory: up to 1 Kbyte true data EEPROM; endurance 300 kcycle
- RAM: up to 2 Kbyte
Clock, reset and supply management
- 2.95 to 5.5 V operating voltage
- Flexible clock control, 4 master clock sources
– Low power crystal resonator oscillator
– External clock input
– Internal, user-trimmable 16 MHz RC
– Internal low-power 128 kHz RC
- Clock security system with clock monitor
- Power management:
– Low-power modes (wait, active-halt, halt)
– Switch-off peripheral clocks individually
- Permanently active, low-consumption poweron and power-down reset
Interrupt management
- Nested interrupt controller with 32 interrupts
- Up to 37 external interrupts on 6 vectors
Communication interfaces
- UART with clock output for synchronous operation, SmartCard, IrDA, LIN master mode
- SPI interface up to 8 Mbit/s
- I2C interface up to 400 kbit/s
Analog to digital converter (ADC)
- 10-bit, ±1 LSB ADC with up to 10 multiplexed channels, scan mode and analog watchdog
