S9S08DZ60F2CLF Microcontroller MCU 40MHz 8-Bit Microcontrollers LQFP-48 Package

S9S08DZ60F2CLF Microcontroller MCU 40MHz 8-Bit Microcontrollers LQFP-48 Package

Product Description Of S9S08DZ60F2CLF
S9S08DZ60F2CLF offers designers scalability and flexibility of migration with pin, peripheral and tool compatibility between S08D family devices.
This highly integrated next generation family of MCUs is packed with features designed to provide increased performance, as well as save power, development time, board space and cost.

Specifications Of S9S08DZ60F2CLF

Features Of S9S08DZ60F2CLF
40 MHz core speed, 20 MHz bus speed on S08 CPU
HC08 instruction set with added BGND instruction
Up to 128 KB flash read/program/erase over full operating voltage and temperature
Up to 2 KB EEPROM in-circuit programmable memory; 8-byte single-page or 4-byte dualpage erase sector; program and erase while executing flash; erase abort
Up to 8 KB RAM (16:1 flash/RAM, ratio better than competition)
Two very low-power stop modes
Very low-power, real-time interrupt for use in run, wait and stop modes
Oscillator (XOSC)—Loop-control Pierce oscillator; crystal or ceramic resonator range of 31.25 kHz–38.4 kHz or 1 MHz–16 MHz
Multi-purpose clock generator (MCG)–PLL and FLL modes; internal reference clock with trim adjustment; external reference with oscillator/resonator options
Watchdog computer operating properly (COP) reset with option to run from dedicated 1 kHz internal clock source or bus clock
Low-voltage detection with reset or interrupt; selectable trip points
Illegal opcode detection with reset
Illegal address detection with reset
Flash block protect
EEPROM block protect

Applications Of S9S08DZ60F2CLF
Automotive
Digital Cluster
Electric Pumps
Heating Ventilation and Air Conditioning (HVAC)
Consumer
Air Conditioning (AC)
Hearables
Major Home Appliances
Robotic Appliance
Small and Medium Appliances
Industrial
Automatic Vehicle Identification
Diabetes Care
Hearing Aids and Cochlear Implants
Heat Meter
Industrial HMI
Patient Monitor
Smart Power Socket
Smart Watch and Wristband
Transport Ticketing
Vital Signs Monitors
